Cast iron fireplace KRATKI SIMPLE right 8 kW Ø 200 installation kit 2

Right Fireplace Insert SIMPLE 8 with Side Glass and Installation Set

Catalog Number: ##SIMPLE/M/S/P/BS/ZESTAW/PODST##

Product Information:

• Double-glazed BS-type inserts with divided glass
• Perfectly fits into the style of modern interiors
• This type of fireplace is often chosen for open spaces
• The fireplace includes as standard:
• ENERGY CLASS A
• CLEAN GLASS SYSTEM
• GRATE
• FLUE DAMPER
• ASH PAN
• DEFLECTOR
• DENSELY ARRANGED RADIATORS
• Heating power range from 3.0 to 10.0 kW
• High efficiency up to 80%
• Front glass withstands up to 660°C
• Installation set for mounting the fireplace in the house

We offer different models of these inserts in our auctions.

THE SET INCLUDES:

1. Cast iron SIMPLE fireplace insert - 1 piece
2. Air intake - 1 piece
3. Transition air intake/pipe 90 degrees - 1 piece
4. Flex 125 degrees - 1 piece
5. Base for the insert - 1 piece
6. Steel pipe for chimney connection: 1 meter Ø 200 - 1 piece
7. Steel pipe for chimney connection: 0.5 meter Ø 200 - 2 pieces
8. Movable steel elbow 90 degrees, Ø 200 - 1 piece
9. Transition from pipe to ceramic chimney Ø 200 - 1 piece
10. Clamps - 2 pieces
11. Cleaning foam for fireplace glass - 1 piece
12. Heat-resistant tape up to 350°C

The installation set was used by our installers to create the following fireplace insert setup.

Your fireplace can look like this.

If you want to change or add any elements to the set, you will find a wide range of fireplace accessories in our other auctions.

Technical data for the insert:

Nominal power (kW): 8

Heating power range (kW): 3.0 - 10.0

Flue diameter (mm): 200

Thermal efficiency (%): 80

CO emission (at 13% O₂) ≤: 0.1%

Dust emission (mg/Nm3): 25

Flue gas temperature °C: 238

Weight (kg): 115

Width (cm): 67.5

Height (cm): 70.1

Depth (cm): 43.3

Max log length (mm): 330

Material: cast iron, steel

Fuel type: recommended seasoned hardwood with moisture ≤20%

BUILT-IN FLUE DAMPER

Allows chimney draft regulation, improving the combustion process efficiency. Regulation is possible with a knob.

ASH PAN DRAWER

Helps keep the insert clean. The knob on the front of the drawer allows air intake regulation. Additionally, the grate inside the insert prevents wood from falling out.

DOOR OPENING SYSTEM IN BS-TYPE CORNER INSERTS

The entire L-shaped door opens in the case of the right corner insert - to the right, and the left corner insert - to the left.

MODERN DESIGN

Corner fireplace insert with BS-type doors (joined glass), equipped with a single glass.

The insert door has a modern handle.

MAXIMUM ENERGY USE

Burning of fuel particles is achieved through the deflector, which extends the flue gas path. This process also increases combustion efficiency and ensures better energy use, thus minimizing harmful emissions to the atmosphere.

Spacious combustion chamber allows loading a large amount of fuel without frequent refueling.

Manual control of the chimney draft via the built-in damper.

TOP-TIER SAFETY

The front of the insert is equipped with heat-resistant ceramic that withstands temperatures up to 660°C. The glass offered by us has a quality and safety certificate.

Densely arranged radiators on the outer walls of the unit ensure maximum heat utilization generated by the insert.

The front of the insert is resistant to high temperatures due to the use of high-quality steel.

CONVENIENT USE

The unit is equipped with a clean glass system – a so-called air curtain evenly distributes the airflow, sweeping the glass and minimizing soot buildup. This helps to maintain an attractive and clean appearance of the glass for a long time.

The removable grate and ash pan make it easier to keep the insert clean.
