Cast iron fireplace KRATKI SIMPLE left 8 kW Ø 200 Set

SIMPLE 8 left fireplace insert with side glass with installation kit

Catalog number:

Product information:

double-sided glazed BS inserts with divided glass
fits perfectly into the style of modern interiors
this type of fireplace is often chosen for open rooms
as standard The fireplace has:
CLASS ENERGY A
CLEAN GLASS SYSTEM
GRATE
SILVER
ASH TRAY
DEFLECTOR
THICKLY AROUND RADIATORS
heating power range
from 3 to 10 kW
high efficiency
up to 80%
front glass withstands
up to 660°C
kit for installing a fireplace at home

We have various models of these inserts at our auctions.

The set includes:

SIMPLE cast iron fireplace insert - 1 pc.
Inlet - 1 pc.
Flex fi 125 degrees - 1 pc.
Base for the insert - 1 pc.
Steel pipes for chimney connection: 0.25 meter fi 200 - 1 pc.
Steel pipes for chimney connection: 0.5 meter fi 200 - 1 pc.
Movable steel elbow, 90 degree angle, fi 200 - 1 pc.
Transition from the pipe to the ceramic chimney, opening diameter 200 - 1 pc.
Damper with pull rod 1 pc.
Insulation boards - 5 pcs.
Max glue for insulating boards - 1 pc.
Grille 17x49 graphite - 2 pcs.
Snail clamp 4 pcs.

The installation kit was used by our installers to install the fireplace insert below.

Your fireplace may look like this.

If you want to change or add an element to the set, you will find a wide selection of fireplace accessories on our other auctions.

Cartridge technical data:

Nominal power (kW): 8

Heating power range (kW): 3-10

Plug diameter (mm): 200

Thermal efficiency (%): 80

CO emissions (at 13% O₂) ≤: 0.10%

Pollen emission (dust) (mg/Nm3): 25

Exhaust gas temperature °C: 238

Weight (kg): 115

Width (cm): 67.5

Height (cm): 70.1

Depth (cm): 43.3

Max log length (mm): 330

Material: cast iron, steel

Type of fuel: recommended seasoned hardwood with humidity ≤20%

Built-in damper

Allows you to adjust the chimney draft, which makes the combustion process more effective. Adjustment is possible using the knob.

ASH DRAWER

Makes it easier to keep the insert clean. The knob at the front of the drawer allows you to regulate the air flow from the room. Additionally, the fence placed in the insert prevents the wood from falling out.

DOOR OPENING SYSTEM IN CORNER BS INSERTS

The entire L-shaped door opens to the right in the right corner insert version and to the left in the left corner insert version.

MODERN DESIGN

Corner fireplace insert with BS type doors (joined glass), equipped with a single glass.

The insert door has a modern handle.

MAXIMUM ENERGY USE

Afterburning of fuel particles thanks to a deflector that extends the exhaust gas path. This process also increases combustion efficiency and ensures better energy use, thus minimizing the emission of harmful substances into the atmosphere.

A spacious combustion chamber that allows you to load a large amount of fuel without the need for frequent refilling.

Manual control of the chimney draft using a built-in damper

SAFETY AT THE HIGHEST LEVEL

The front of the insert is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C. The glass we offer has a quality and safety certificate.

Densely arranged heat sinks on the outer walls of the device guarantee maximum use of the heat generated by the insert.

The front of the insert is resistant to high temperatures thanks to the use of high-quality steel.

COMFORTABLE USE

The device is equipped with a clean glass system - thanks to the so-called in the curtain, the air stream is distributed evenly, sweeps the glass and minimizes soot deposition on it. This allows you to maintain the attractive and clean appearance of the glass for a long time.

The removable grate and ash pan make it easier to keep the insert clean.
