Cast iron fireplace KRATKI SIMPLE left 8 kW Ø 200 Set 2

Simple 8 Right Fireplace Insert with Side Glass and Mounting Kit

Catalog Number: ##SIMPLE/M/S/P/BS/ZABUDOWA/2##

Product Information:

• Double-glazed BS inserts with split glass
• Perfectly fits into the style of modern interiors
• This type of fireplace is often chosen for open-plan spaces
• The fireplace comes standard with:
• ENERGY CLASS A
• CLEAN GLASS SYSTEM
• GRATE
• DAMPER
• ASH PAN
• DEFLECTOR
• DENSELY PLACED RADIATORS
• Heating power range from 5.7 to 14.5 kW
• High efficiency of up to 75%
• The front glass withstands up to 660°C
• Mounting kit for installation in your home

We have various models of these inserts available in our auctions.

THE KIT INCLUDES:

1. Cast iron Simple fireplace insert - 1 piece
2. Air intake - 1 piece
3. Flex pipe 125 degrees - 1 piece
4. Base for the insert - 1 piece
5. Steel pipe for chimney connection: 0.25 meters, 200mm - 1 piece
6. Steel pipe for chimney connection: 0.5 meters, 200mm - 1 piece
7. Movable steel elbow 90 degrees, 200mm - 1 piece
8. Pipe-to-ceramic chimney transition, 200mm - 1 piece
9. Damper with rod - 1 piece
10. Insulation plates - 5 pieces
11. Max adhesive for insulation plates - 1 piece
12. LUFT SF left corner black 76.6x54.7x9 - 1 piece
13. LUFT SF right corner black 54.7x76.6x9 - 1 piece
14. Clamp screw - 4 pieces

The mounting kit was used by our installers to build the fireplace insert setup below.

Your fireplace could look like this.

If you wish to change or add any elements to the kit, you will find a wide range of fireplace accessories in our other auctions.

Technical data of the insert:

Nominal power (kW): 11

Heating power range (kW): 5.7-14.5

Chimney pipe diameter (mm): 200

Thermal efficiency (%): 75

CO emission (at 13% O₂) ≤: 0.20%

Particle emission (mg/Nm3): 29

Flue gas temperature (°C): 345

Weight (kg): 115

Width (cm): 67.5

Height (cm): 70.1

Depth (cm): 43.3

Max log length (mm): 330

Material: Cast iron, steel

Fuel type: Recommended seasoned hardwood with moisture ≤20%

BUILT-IN DAMPER

Allows control of the chimney draft, which influences a more efficient combustion process. Regulation is possible via a knob.

ASH PAN DRAWER

Facilitates cleaning of the insert. The knob at the front of the drawer allows the regulation of the air intake from the room. Additionally, the fence inside the insert prevents the logs from falling out.

DOOR OPENING SYSTEM IN CORNER BS INSERTS

The entire L-shaped door opens in the case of the right corner insert – to the right, and the left corner insert – to the left.

MODERN DESIGN

Corner fireplace insert with BS doors (joined glass), equipped with a single glass.

The doors of the insert feature a modern handle.

MAXIMUM ENERGY UTILIZATION

Afterburning fuel particles thanks to the deflector, which extends the flue gas path. This process also increases combustion efficiency and ensures better energy utilization, thus minimizing harmful emissions into the atmosphere.

Spacious combustion chamber, allowing for loading a large amount of fuel without the need for frequent refueling.

Manual chimney draft control via the built-in damper.

SAFETY AT THE HIGHEST LEVEL

The front of the insert is equipped with heat-resistant ceramic that withstands temperatures up to 660°C. The glass we offer is certified for quality and safety.

The fireplace is resistant to high temperatures due to the use of high-quality steel.

CONVENIENT USAGE

The device is equipped with a clean glass system – thanks to the so-called air curtain, the airflow is evenly distributed, sweeping the glass and minimizing soot buildup on it. This helps to maintain the elegant and clean appearance of the glass for a long time.

The removable grate and ash pan make it easier to keep the insert clean.
