Wood burning steel stove KRATKI AB 2 Ø 150 10 kW
- Ecodesign
- Designed for recuperation
- BImSchV 2
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Full combustion on the dust thanks to two deflectors extending the exhaust path.
Triple system of combustion chamber`s air venting: primary air - secondary air supplied under the grate through holes in a back wall. Additionally clean glass system designed (air curtain).
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Built-in fi 125 external air intake which provides air supply from the outside directly into the hearth which results in better combustion and better comfort of usage.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Front is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
CONVENIENT TO USE
Movable grate and ash drawer enable to keep the stove clean.
Reduced soot deposition through a system of pure glass (air curtain).
Elegant and comfortable sliding handle.
It can be used in a various mounting conditions thanks to adjustable exhaust outlet: on the back or top of the stove (for back exhaust outlet installation purchase of top plate cover is required).
MODERN DESIGN
The chamber below the furnaces is equipped with a mechanism push to open - press to open.
Improved vision of the fire thanks to the curved glass
Technical data
Rated output (kW) | 10 |
---|---|
Heating power range (kW) | 4.0 - 12.0 |
Heating efficiency (%) | 80 |
Exhaust gas temperature (℃) | 280 |
Max length of logs (cm) | 50 |
Color | Black |
Self Closure | No |
Door opening direction | Left |
Materials | Steel |
Flue outlet diameter (mm) | 150 |
Air intake diameter (mm) | 125 |
Energy class | A |
---|---|
Energy efficiency index (EEI) | 105.4 |
Moc cieplna do ogrzewania pomieszczeń (kW) | 10 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.09 |
Dust emission (mg/Nm3) | 15 |
Meets requirements | Ecodesign, Designed for recuperation, BImSchV 2 |
---|
Design features | Air intake - built in , Ashpan, Combustion chamber lining |
---|---|
Front type | Steel front with ceramic glass |
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5901350083802 |
Width (cm) | 76.1 |
---|---|
Height (cm) | 105.2 |
Depth (cm) | 46 |
