Wood burning steel stove KRATKI ROLLO 7 kW Ø 150

star star star star star
Reviews: 0
Wood burning steel stove KRATKI ROLLO 7 kW Ø 150
Designations
Sku ROLLO/KONF
Specification
Rated output (kW) 7
Heating efficiency (%) 80
Energy class Energy card (UE) 2015/1186
Meets requirements
  • Ecodesign
  • Designed for recuperation
  • BImSchV 2
Shipping
Availability 14 days of implementation Medium Stock: 43
Expected delivery date 22.01 - 23.01
Shipping from €71.76
Lining color
White
Black
Or pay directly:
From €981.31
Price includes VAT
Additional products 17
Spare parts 3

Description

  • Teaser image

ROLLO steel stove - heats from 40 m² to 100 m²

  • The ROLLO steel stove combines functionality and universal design, making it an attractive element in interior design. The ROLLO stove creates a cosy atmosphere in the home thanks to the possibility of freely watching the flames. It easily adapts to different interior styles, from modern to rustic. This flexibility allows the stove to be integrated into various design concepts.

    ROLLO is available with white or black TERMOTEC lining.

  • Teaser image

ROLLO stove complies with ecodesign requirements and the German BlmSchV 2 standard

  • Teaser image
  • Teaser image

ADVANTAGES

  • Heat-resistant glass

    Heat-resistant glass

    Renowned manufacturer SCHOTT ROBAX, glass with a temperature resistance of up to 600°C,

  • Perforated handle

    Perforated handle

    Causes it to cool down naturally. Oval-shaped handle with perforations that allow a secure grip and prevent excessive heat build-up.

  • TERMOTEC lining

    TERMOTEC lining

    This is a heat-accumulating material that increases the temperature in the firebox. It ensures more efficient combustion and longer temperature retention. As a result, when the fireplace is extinguished, the heat is still transferred to the room in which it is located for a long time. Choice of white or black colour.

  • Cast iron grate

    Cast iron grate

    Ensures even and efficient combustion of wood, leading to better fuel utilisation and increased heat output.

  • Steel ash pan

    Steel ash pan

    The ash pan is positioned below the combustion chamber and access to it is easy as it does not require the removal of the grate, which makes it easy to empty the ash collecting in it. The entire cleaning process of the stove is fast, convenient and comfortable.

  • Adjustment of air supply

    Adjustment of air supply

    It is based on an intuitive and simple mechanism that allows you to easily control the amount of air supplied to the stove. Pulling out the slide opens the air supply, while fully retracting it cuts it off. Clear markings translate into trouble-free and convenient use.

  • Push-to-open mechanism

    Push-to-open mechanism

    The chamber under the firebox is equipped with a push-to-open mechanism. The mechanism makes it possible to open the door by gently pressing it, without using conventional handles or grips. It provides̨ convenience of use and an aesthetically pleasing appearance.

  • Material of construction

    Material of construction

    The use of high-quality steel in the body and front of the ROLLO stove ensures not only resistance to high temperatures, but also stability of the construction. The top plate of the stove is made of 5 mm thick steel. This is particularly important for safety, as well as the long-term use of the stove.

Built-in air intake

Via external spigot (can be connected from the rear as well as from the bottom) with a diameter of fi 100

Efficient heating

The triple air circulation contributes to a highly efficient combustion process.

  • Teaser image

  • The ROLLO stove uses a triple system of combustion chamber aeration. The primary air, which facilitates lighting of the wood, is supplied under the grate. Secondary air, ensuring ecological combustion, is supplied through holes in the rear wall of the stove. The air curtain efficiently supplies air directly to the glass through a system of ducts located on the sides of the stove. In this way, the gases produced during wood combustion are post-combusted, further reducing the emission of harmful CO into the atmosphere.

    The stove is equipped with a deflector which provides a natural convection channel for the flue gas flow, improving the flue gas flow and intensifying heat exchange. As a result, the stove burns fuel more efficiently, makes better use of energy and reduces harmful emissions into the atmosphere.

Technical data

General data
Rated output (kW)7
Heating power range (kW)4 - 10
Heating efficiency (%)80
Exhaust gas temperature (℃)269
Max length of logs (cm)25
ColorBlack
Self ClosureYes
Door opening directionLeft
MaterialsSteel
Flue outlet diameter (mm)150
Air intake diameter (mm)100
Energetic efficiency
Energy classA
Energy efficiency index (EEI)106
Seasonal Heating efficiency (%)70
Thermal power for space heating (kW)7
CO emissions (at 13% O 2 ) ≤ given in %0.044
CO emission (mg/m3)555
Dust emission (mg/Nm3)19
NOx emission (mg/m3)103
OGC emission (mg/m3)63
Flue gases mass flow rate (g/s)6.2
Certifications / Compliance
Meets requirementsEcodesign, Designed for recuperation, BImSchV 2
Additional information
Design featuresAir intake - built in , Ashpan, Combustion chamber lining
Front typeSteel front with ceramic glass
Type of fuelSeasoned deciduous wood (humidity ≤20%)
EAN5903751182481
Physical parameters
Width (cm)52.6
Height (cm)97.6
Depth (cm)40.2

Documentation

Product card Download file Instruction EU_koza_stalowa.pdf.pdf Download file Ecodesign ROLLO_Ecodesign_EU_2015_1185.pdf.pdf Download file Declaration of performance DoP_ROLLO.pdf.pdf Download file Technical drawing Download file Energy card (UE) 2015/1186 Download file

Customer reviews

This product has no reviews yet.
Have this product?
Rate Wood burning steel stove KRATKI ROLLO 7 kW Ø 150 and help others to make a choice.

Store reviews

You're reviewing: Wood burning steel stove KRATKI ROLLO 7 kW Ø 150

Select your rating
Tooltip

    Warranty and returns

    Warranty

    All the products available at www.kratki.com are brand new, free from any physical or legal defects. The Producer grants a 5-year warranty from the moment of purchase of a stove for its reliable operation. Grate and sealing for the stove are covered with a 1-year warranty from the moment of the purchase of the stove. The warranty shall not cover heat-resistant ceramics. The application of the stove, the method of joining with the chimney as well as the terms and conditions of use must correspond with the manual.

    Returns

    A Customer being a Consumer, who has concluded the Sales Contract may rescind thereof within a period of 14 days without giving any reasons. The time limits run for the rescission of the Sales Contract shall commence at the time of acquiring the Goods by the Customer or a third party of their choice, other, however, than a carrier. The representations may be submitted in a form whose template has been published by the Seller at the Online Shop Website.
