Wood burning cast iron stove KRATKI K9 Ø 150 9 kW with accessories
Description
MAXIMUM USE OF ENERGY
Maximum use of heat and trouble-free operation thanks to the walls of the device made of high-quality cast iron with a thickness of 8 mm.
Combustion of fuel particles thanks to the deflector, which extends the exhaust gas path.
SAFETY AT THE HIGHEST LEVEL
The Classic front of the stove is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C.
Decorative fence helps to maintain tidiness and protects against falling out of wood.
CONVENIENT TO USE
The cold handle system allows for disassembly when the stove is in use.
Ash drawer/ashtray, where burnt wood remains are gathered and grated for easy ash removal.
Reduced soot deposition through a system of pure glass (air curtain).
The possibility of different assembly, thanks to the adjustable flue gas outlet from the back or top of the stove.
KIT CONTAINS
- Cast iron stove K9
- Montage set of steel pipes
Technical data
Rated output (kW) | 10.5 |
---|---|
Heating power range (kW) | 8,5 - 12,5 |
Heating efficiency (%) | 75.3 |
Exhaust gas temperature (℃) | 289 |
Max length of logs (cm) | 25 |
Color | Black |
Self Closure | No |
Additional equipment | None |
Materials | Cast iron |
Flue outlet diameter (mm) | 150 |
Energy class | A |
---|---|
Energy efficiency index (EEI) | 99.2 |
Seasonal Heating efficiency (%) | 65.3 |
Thermal power for space heating (kW) | 10.5 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.148 |
CO emission (mg/m3) | 1856 |
Dust emission (mg/Nm3) | 14 |
NOx emission (mg/m3) | 108 |
OGC emission (mg/m3) | 78 |
Meets requirements | Ecodesign |
---|
Front type | Cast iron front with ceramic glass |
---|---|
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5903751028017 |
Width (cm) | 77.5 |
---|---|
Height (cm) | 69.9 |
Depth (cm) | 54.6 |
Weight (kg) | 180.1 |
