Designations
Sku ZUZIA/PW/15/W/DECO
Specification
Rated output (kW) 12
Heating efficiency (%) 81
Meets requirements
  • Ecodesign
  • BImSchV 2
Weight (kg) 182
Shipping
Availability 1 day of implementation Medium Stock: 12
Expected delivery date 04.12 - 05.12
Shipping from €70.60
Or pay directly:
€1,721.96
Price includes VAT

Description

MAXIMUM USE OF ENERGY

The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.

Built in smoke tubes and high flue, which increase the heat exchange surface.

Increased heat exchange surface due to built-in smoke tubes and high flue.

Regulation of chimney draft using built-in damper.

Manual control over the combustion process carried out by ash tray regulator.



SAFETY AT THE HIGHEST LEVEL

Perfect tightness thanks to the solid welds made in a noble gas shielding.

All steel elements are laser cut and bent on CNC bending machines.

Protection against overheating by the built-in coil pipe - connector input / output 1/2”.



ECOLOGICAL COMBUSTION

The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.



CONVENIENT TO USE

Decorative fence helps to maintain the tidiness and protects against falling out of wood.

Movable grate and ashpan enables to clean the insert.

Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.



Technical data

General data
Rated output (kW)12
Heating power range (kW)5.0 - 15.0
Heating efficiency (%)81
Max working pressure (bar)2
Water capacity (l)38
Exhaust gas temperature (℃)255
Max length of logs (cm)40
Min outlet grids active field (cm2)240
Min inlet grids active field (cm2)120
Door opening directionLeft
MaterialsSteel, Cast iron
Self ClosureNo
Flue outlet diameter (mm)200
Energetic efficiency
Energy classA
Average power from water (kW)8
Thermal power for space heating (kW)4
Energy efficiency index (EEI)106.7
Dust emission (mg/Nm3)33
CO emissions (at 13% O 2 ) ≤ given in %0.09
Certifications / Compliance
Meets requirementsEcodesign, BImSchV 2
Additional information
EAN5901350062753
Design featuresAshpan, Combustion chamber lining, Decorative glass
Type of fuelSeasoned deciduous wood (humidity ≤20%)
Physical parameters
Width (cm)65.2
Height (cm)86.9
Depth (cm)48.9
Weight (kg)182
