Water heating fireplace KRATKI ZUZIA DECO 12 kW Ø 200
- Ecodesign
- BImSchV 2
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Built in smoke tubes and high flue, which increase the heat exchange surface.
Increased heat exchange surface due to built-in smoke tubes and high flue.
Regulation of chimney draft using built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Protection against overheating by the built-in coil pipe - connector input / output 1/2”.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
Movable grate and ashpan enables to clean the insert.
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Technical data
Rated output (kW) | 12 |
---|---|
Heating power range (kW) | 5.0 - 15.0 |
Heating efficiency (%) | 81 |
Max working pressure (bar) | 2 |
Water capacity (l) | 38 |
Exhaust gas temperature (℃) | 255 |
Max length of logs (cm) | 40 |
Min outlet grids active field (cm2) | 240 |
Min inlet grids active field (cm2) | 120 |
Door opening direction | Left |
Materials | Steel, Cast iron |
Self Closure | No |
Flue outlet diameter (mm) | 200 |
Energy class | A |
---|---|
Average power from water (kW) | 8 |
Thermal power for space heating (kW) | 4 |
Energy efficiency index (EEI) | 106.7 |
Dust emission (mg/Nm3) | 33 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.09 |
Meets requirements | Ecodesign, BImSchV 2 |
---|
EAN | 5901350062753 |
---|---|
Design features | Ashpan, Combustion chamber lining, Decorative glass |
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
Width (cm) | 65.2 |
---|---|
Height (cm) | 86.9 |
Depth (cm) | 48.9 |
Weight (kg) | 182 |
