Designations
Sku MBZ/PW/13/W
Specification
Rated output (kW) 13
Heating efficiency (%) 81
Meets requirements
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Weight (kg) 262
Shipping
Availability 14 days of implementation In productionn
Expected delivery date 22.01 - 23.01
Shipping from €102.51
€1,015.65Price includes VATPAKADAMDW200
Availability: 14 Days
€147.19Price includes VATBLENDA/MBZ Availability: 14 Days
€36.91Price includes VATDOMYKANIE/L/7 Availability: 14 Days
€119.16Price includes VATKOSZ/O Availability: 14 Days
€57.95Price includes VATKOSZ/W Availability: 14 Days
€57.95Price includes VATKOSZ/X Availability: 14 Days
€4.40Price includes VATROZETA/SO200 Availability: 14 Days
€36.44Price includes VATPRZ/200 Availability: 14 Days
€43.22Price includes VATPODSTAWA/MB/LUCY Availability: 14 Days
€1.06Price includes VATOPASKA/SLIMAKOWA Availability: 14 Days
€36.91Price includes VATKLEJ/MAX Availability: 14 Days
€11.17Price includes VATKLEJ/K-84 Availability: 14 Days
€5.93Price includes VATSILIKON/1200 Availability: 14 Days
€15.19Price includes VATTASMA/350 Availability: 14 Days
€0.75Price includes VATKOLEK Availability: 14 Days
€7.49Price includes VATREWIZJA/15/B Availability: 14 Days
€5.61Price includes VATZAPALARKA/KRATKI.COM Availability: 14 Days
€106.70Price includes VATNWO/U Availability: 14 Days
€521.03Price includes VATZPW2K15 Availability: 14 Days
€87.88Price includes VATSTS-20.S Availability: 14 Days
€52.29Price includes VATSVH25-1 Availability: 14 Days
€11.81Price includes VATSVH/E25-1/2 Availability: 14 Days
€245.32Price includes VATRS25/6EA Availability: 14 Days
€43.46Price includes VATKLAMKA/PERFOROWANA/MB/LUCY Availability: 14 Days
€3.24Price includes VATSZNUR/W/CZARNY/PODKLEJANY Availability: 14 Days
€1.17Price includes VATSZNUR/W/P/K/10X1 Availability: 14 Days
€1.33Price includes VATSZNUR/W/O/14 Availability: 14 Days
€278.67Price includes VATTERMOTEC/MB-Z Availability: 14 Days
€252.33Price includes VATS/4/G/584X474/MB-Z/SS Availability: 14 Days
€10.74Price includes VATLISTWA/GLASS/MBZ V2 Availability: 14 Days
Description
MAXIMUM USE OF ENERGY
Made of high quality steel resistant to very high temperatures.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Special water system which allows that big amount of the heat from fumes is transferred into heating system, thanks to that high energy efficiency is obtained.
Protection against overheating by the built-in coil pipe - connector input / output 1/2”.
Fireplace`s doors resistant to tensions and stable thanks to the use of closed profile. Door seals designed in profiled canal what guarantees proper adherence and protects against ewentual falling out while operating.
More ecological combustion thanks to double deflector system which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm with throttle valve. Air adjustment with just one regulator which prevents from improper usage.
Triple system of combustion chamber`s air venting: primary air - secondary air supplied under the grate through holes in a back wall. Additionally clean glass system designed (air curtain).
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum. The bottom plate of the insert is significantly reduced relative to the door.
Reduced soot deposition through a system of pure glass (air curtain).
The special perforated design of the handle protects against excessive heating, which has the influence on the high comfort of using the fireplace.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Doors are equipped with modern handle.
Technical data
| Rated output (kW) | 13 |
|---|---|
| Heating power range (kW) | 6.0 - 16.0 |
| Heating efficiency (%) | 81 |
| Max working pressure (bar) | 2 |
| Water capacity (l) | 35 |
| Exhaust gas temperature (℃) | 230 |
| Max length of logs (cm) | 50 |
| Min outlet grids active field (cm2) | 360 |
| Min inlet grids active field (cm2) | 180 |
| Door opening direction | Left |
| Materials | Steel |
| Self Closure | No |
| Flue outlet diameter (mm) | 200 |
| Energy class | A |
|---|---|
| Average power from water (kW) | 7 |
| Thermal power for space heating (kW) | 6 |
| Energy efficiency index (EEI) | 106.705 |
| Dust emission (mg/Nm3) | 32 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.1 |
| Meets requirements | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| EAN | 5901350033562 |
|---|---|
| Design features | Air intake - built in , Combustion chamber lining, Decorative glass |
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 73 |
|---|---|
| Height (cm) | 133.5 |
| Depth (cm) | 47.9 |
| Weight (kg) | 262 |
