Water heating fireplace KRATKI LUCY 12 kW Ø 200 black thermotec lining

Maximum power use

Efficient combustion and longer maintenance of temperature thanks to the burning chamber of the thermotec, the heat accumulating material, which increases the temperature in the furnace.

Pouring fuel particles thanks to two deflectors that extend the exhaust gas. This process also increases the efficiency of combustion and ensures better use of energy, and thus minimizes the emission of harmful substances into the atmosphere.

Delivery of air to the cartridge takes exclusively from the outside, thanks to the built-in air intake pipe FI 125 mm. Its adjustment takes place by means of a throttle set with one controller below the door, which excludes errors in improper use. The entire mechanism works very quiet and trouble.

In the cartridge, a double combustion chamber containing system is used. The primary air, facilitating wood firing, is delivered under the grate. In addition, the cleaning glass system (air curtain) is used in the cartridge, i.e. the air is delivered directly to the window through the channel system placed on the sides of the fireplace. In this way, oxygen is supplied to the upper part of the combustion chamber, in which the gas burning gases occurs in the wood combustion process, which additionally limits the emission of harmful to the atmosphere.

The use of such a package system allows very precise combustion process control.

Ecological combustion

The device meets the requirements and bimschv 2 standard, determining the maximum CO emission.

Security at the highest level

Front of the cartridge equipped with a heat-resistant ceramics that can withstand the temperature up to 660 ° C. The glass offered by us has a quality and safety certificate.

Special perforated handle design protects against excessive heating, which affects the high comfort of the fireplace.

Body and front cartridge resistant to high temperatures thanks to high-quality steel.

Excellent tightness, thanks to solid welds made in a noble gas shield. Laser cut steel elements with modern devices, and then bent on CNC bending machines.

Comfortable use

In the fireplace a specially profiled bottom plate made of thermotec material has been used, thanks to which the combustion chamber is deeper and it contains a larger amount of wood.

Removable grate and panel make it easier to keep the cartridge clean.

The limited deposition of the soot takes place thanks to the cleaning glass used.

The air curtain separates the glass from the furnace. Thanks to this, it does not dirty more heat to the room.

The ability to reduce substrate inequalities and cancellation of the cartridge thanks to adjustable legs.

Model equipped with a movable flue gas outlet, thanks to which in the case of assembly, there is no need to buy additional knees. You can easily adjust the connecting angle of the cartridge to the chimney installation.

Modern Design

The cartridge is equipped with two front and rear door (instead of the back wall), thanks to which the heat radiates in two directions.

This type of fireplace is a frequently chosen solution for mounting between neighboring rooms, eg a living room and a dining room or bedroom.

The cartridge is equipped with a single, decorative glass glass window, thanks to which it looks elegant and modern.

The use of this solution optically enlarges the front of the cartridge and emphasizes the vision of the fire.

The cartridge door has a comfortable handle.

Layout - black thermotec.
