• PRO

Wall-hung stove AB ENYO R VIEW 5.5 kW Ø 150 with wall hanger

Designations
Sku KOZA/AB/ENYO/R/VIEW/WISZACY
Specification
Nominal power (kW) 5.5
Thermal Efficiency (%) 80.5
Certificates
  • KRATKI PRO
  • Ecodesign
  • Designed for recuperation
  • BImSchV 2
Weight (kg) 131

Description

Modern AB ENYO R VIEW Stove with a Practical Wall Hanger

The AB ENYO R VIEW Stove with a wall hanger is a modern wall-mounted stove that adds a touch of lightness to any interior and enhances its elegant character. Wall mounting allows for optimal use of space and allows for adjusting the stove's height to individual user needs. The raised stove makes adding wood more convenient and ergonomic, and the free space beneath the stove allows for a storage area. This solution was created for modern interiors where both design and comfort of use are important.

This solution not only heats efficiently (suitable for areas of approximately 60 m²), but also creates a cozy atmosphere, opening the room to a beautiful vision of fire from three sides.

Technology for the Environment

The AB ENYO R VIEW stove meets the strict environmental requirements of regional regulations regarding emission standards for fireplaces and other solid fuel heating appliances, including: Ecodesign, BImSchV 2. It has also been tested to the rigorous EN 16510 standard. This guarantees clean combustion, low emissions, and high energy efficiency.

Quality, Durability, and Comfort of Use

The stove's construction, made of high-grade, high-temperature-resistant steel, ensures stability and safety for years to come. The front and sides are equipped with heat-resistant glass resistant to high temperatures up to 660°C, and the elegant, long railing handle ensures ease of use, complementing the modern design of the entire device.

Why choose AB ENYO R VIEW with a wall hanger?

Modern suspended structure - makes the stove an architectural element of the interior, emphasizing its modern character,
Optical enlargement of the interior - the raised form gives the room a feeling of lightness and makes the space seem more open,
Greater arrangement freedom - the lack of a base allows for better use of the space under the stove - for wood, decorations, or leaving an empty space.
Height adapted to your needs - the ability to install at an individually selected height increases comfort of use,
Ergonomic Operation - the raised firebox makes lighting and adding wood easier, reducing the need to bend down.
■ Better floor exposure - the lack of a base allows for the floor finish to be exposed and reduces the point load at the installation site.
■ Three-sided glazing - a unique view of the flames from the front and sides creates an impressive atmosphere in the room.
■ TERMOTEC lining - longer temperature retention thanks to the TERMOTEC combustion chamber lining (available in white or black),
■ Intuitive air supply regulation - using a single element,
■ Elegant handle in the form of a long railing - provides a comfortable grip along the entire length,
■ Standard closing system - the stove is equipped with a mechanism that automatically closes the door
Clean glass system (air curtain) - allowing you to enjoy a pristine view of the flames,
Heat-resistant glass - with temperature resistance up to 660°C,
Triple combustion chamber ventilation system - guaranteeing high efficiency and economical combustion,
Deflector - extending the exhaust gas path for optimal energy use,
Deeper combustion chamber - which holds more wood and prevents ash spillage,
High-quality coating - the stove is covered with paint with increased scratch resistance and uniform structure,

Technical specifications for installation

The stove is mounted on a steel wall hanger, which is attached to walls (recommended installation using chemical anchors with M10 threaded rods). This solution ensures durable and stable fastening, provided that appropriate anchors are used and installation is correct, depending on the type of substrate.

Approximate load-bearing capacity of a single fastening point with an M10 chemical anchor (depending on the substrate):
■ Solid concrete (C20/25–C30/37): approx. 300–600 kg,
■ Solid brick: approx. 200–400 kg,
■ Ceramic block or hollow ceramic brick: approx. 80–150 kg,
■ Aerated concrete (Ytong): approx. 50–100 kg.

The actual load-bearing capacity is primarily influenced by:
■ embedment depth; For M10 rods, 80–90 mm in concrete is usually recommended,
■ type and condition of the substrate,
■ accuracy of installation; the hole should be thoroughly cleaned (brushing and blowing at least 2–3 times), any dust left behind may reduce the anchor's load-bearing capacity by up to 50%.

Technical data

General data
Nominal power (kW)5.5
Thermal Efficiency (%)80.5
Flue gas temperature (°C)297
Optimal log length (mm)250
Max billet length (cm)35
Base materialSteel
diameter of the flue gas outlet150
Air intake diameter (mm)100
Energetic efficiency
Energy classA
EEI106.7
Seasonal Energy Efficiency (%)70.5
Heat output for space heating (kW)5.5
CO emission (at 13% O2) ≤ given in %0.077
CO emission (mg/m3)965
Pollen emission (mg/m3)21
NOx emission (mg/m3)117
OGC emission (mg/m3)103
Flue gas mass flow (g/s)4
Certifications / Compliance
CertificatesKRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2
Additional information
EAN5903751399179
Fuel typeSeasoned deciduous wood (humidity ≤20%)
Physical parameters
Width (cm)51
Height (cm)93.1
Depth (cm)43
Weight (kg)131
