Designations
Sku NADIA/13/DG
Specification
Rated output (kW) 13
Heating efficiency (%) 81
Meets requirements Ecodesign
Weight (kg) 178
Shipping
Availability 14 days of implementation Low stock
Expected delivery date 22.01 - 23.01
Shipping from €102.51
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air).
The cleanliness of combustion chamber thanks to hexagonal hearth.
Fireplace with double glass version which improves more efficient heating radiation to the rooms as well as ensures less fireplace glazing contamination.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum.
Reduced soot deposition through a system of pure glass (air curtain).
It can be used in a various mounting conditions thanks to adjustable legs and movable fumes outlet with 360 regulation.
Possibillity to change the direction of door opening from a standard left-hand opening to the right-hand opening.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Elegant and comfortable sliding handle.
Technical data
| Rated output (kW) | 13 |
|---|---|
| Heating power range (kW) | 6.0 - 16.5 |
| Heating efficiency (%) | 81 |
| Exhaust gas temperature (℃) | 240 |
| Max length of logs (cm) | 40 |
| Min inlet grids active field (cm2) | ≥700 |
| Min outlet grids active field (cm2) | ≥900 |
| Flue outlet diameter (mm) | 200 |
| Materials | Steel |
| Door opening direction | Left |
| Energy class | A |
|---|---|
| Energy efficiency index (EEI) | 106.71 |
| Thermal power for space heating (kW) | 13 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.09 |
| Dust emission (mg/Nm3) | 37 |
| Meets requirements | Ecodesign |
|---|
| Design features | Air intake - built in |
|---|---|
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
| EAN | 5901350079416 |
| Width (cm) | 83.4 |
|---|---|
| Height (cm) | 133.1 |
| Depth (cm) | 41.8 |
| Weight (kg) | 178 |
