Steel fireplace KRATKI LUCY SLIM EKO right 8 kW Ø 160 installation kit

3 to 10 kW

high

efficiency up to 83%

panoramic glazing with

decorative GLASS

mounting kit

SET INCLUDES:

LUCY SLIM RIGHT BS 12 kW air fireplace insert - 1 pc.

Screw-drive clamp - 4 pcs.

Max adhesive for insulation boards - 1 pc.

Joint adhesive - 3 pcs.

Plugs for mounting boards - 16 pcs.

Flex Ø 125 degrees - 1 pc.

Insert base - 1 pc.

Steel pipes for chimney connection: 1 meter Ø 160 - 1 pc.

Steel pipes for chimney connection: 0.5 meters Ø 160 - 1 pc.

Movable steel elbow, 90 degrees, Ø 160 - 1 pc.

Transition with reduction from the pipe system Ø 160/200 - 1 pc.

Insulation boards for installation - 20 pcs.

LUFT grille, black, corner, right 9x40x60 - 2 pcs.

LUFT SF left corner grille, black, 9x40x60 - 1 pc.

Rosette, diameter 125 - 1 pc.

Steel frame, 90° for insert - 1 pc.

Connection for a 17/17 Ø 125 grille - 1 pc.

Grille 17/17 white - 1 pc.

The assembly kit was used by our installers to build the presented LUCY fireplace insert.

Your fireplace may look just like the one our installers built it.

Technical data:

Nominal power (kW): 8

Heating power range (kW): 3-10

Smoke conduit diameter (mm): 160

Thermal efficiency (%): 83

CO emissions (at 13% O₂) ≤: 0.09%

Particulate matter (dust) emissions (mg/Nm3): 9

Exhaust gas temperature °C: 180

Weight (kg): 171.0

Width (cm): 78.1

Height (cm): 128.2

Depth (cm): 41.5

Maximum log length (mm): 350

Material: steel

Fuel type: recommended seasoned hardwood with moisture content ≤20%

Movable exhaust outlet.

Triple chamber ventilation system exhaust.

Elegance and a comfortable handle.

Adjustable leg height.

Precise air damper control.

Built-in air intake.

Decorative glass with an air curtain (clean glass system)

Termotec lining.

ORNACTED GOLD AND SILVER HANDLES

The fireplace has replaceable handle handles. You can buy gold or silver handles at our other auctions. The excellent material quality and special perforated design ensure comfortable use.

ROTATING EXHAUST OUTLET

The exhaust outlet can be adjusted for easier insert connection. 360° adjustment Allows for the exhaust outlet to be connected to the rear or top of the insert.

DECORATIVE GLASS

The insert is equipped with a single, decorative glass pane, giving it an elegant and modern look. This solution visually enlarges the front of the insert and highlights the fire.

REMOVABLE GRATE

Allows access to the ash container, making it easier to keep the insert clean.

THERMOTEC LINING

The combustion chamber is lined with THERMOTEC heat-accumulating material, which increases the temperature in the fireplace. This makes combustion more environmentally friendly, and maintains a high temperature for a longer period of time.

CLEAN GLASS SYSTEM

The air guide, which is mounted at the top of the insert front, reduces soot buildup.

ADJUSTABLE FEET

Allows for perfect leveling of the insert relative to the ground during installation.

BUILT-IN AIR INTAKE ADJUSTMENT

The outside air supply is regulated using the built-in damper located below the door. The entire mechanism operates inside the fireplace, very quietly and reliably.

INNOVATIVE HANDLE

The special perforated handle design protects against excessive heat, ensuring high comfort of use.

This interestingly shaped insert features side glazing and a shallow combustion chamber, making it perfect for small living rooms with low heating requirements. With its double-sided fire viewing and delicate front frame, it blends seamlessly into the style of modern interiors. Modern solutions used in the fireplace guarantee energy savings and make operation and cleaning hassle-free.

MAXIMUM ENERGY USE

More efficient combustion and longer temperature retention thanks to the THERMOTEC combustion chamber lining, a heat-accumulating material that raises the temperature in the combustion chamber.

Fuel particles are burned thanks to two deflectors that extend the exhaust gas path. This process also increases combustion efficiency and guarantees better energy utilization, thus minimizing harmful emissions into the atmosphere.

Air is supplied to the insert exclusively from the outside, thanks to the built-in 125 mm air intake connector. It is adjusted using a single damper located below the door, eliminating errors resulting from improper use. The entire mechanism operates very quietly and flawlessly.

The insert features a triple combustion chamber ventilation system. Primary air, facilitating wood ignition, is supplied under the grate. Secondary air, ensuring economical and ecological combustion, is supplied through holes in the rear wall.

Additionally, the insert features a clean glass system (air curtain), which means air is delivered directly to the glass through a system of channels located on the sides of the fireplace. This delivers oxygen to the upper part of the combustion chamber, where the gases produced during wood combustion are burned, further reducing harmful CO emissions into the atmosphere.

The use of this air supply system allows for very precise control of the combustion process.

ECOLOGICAL COMBUSTION

The device meets the requirements of Ecodesign and the BImSchV 2 standard, which sets maximum CO emissions.

SAFETY AT THE HIGHEST LEVEL

The front of the insert is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C. The glass we offer is certified for quality and safety.

The body and front of the insert are resistant to high temperatures thanks to the use of high-quality steel.

Excellent tightness thanks to solid welds made in a noble gas shield. Steel elements are laser-cut using modern equipment and then bent on CNC bending machines.

COMFORTABLE TO USE

In SLIM fireplaces, the combustion chamber is much shallower. At the same time, thanks to the deepened bottom, it holds a sufficient amount of wood. This means that emptying the firebox of ash is much less frequent. Furthermore, the removable grate and ash pan make it easier to keep the insert clean.

Limited soot buildup is achieved thanks to the clean glass system. An air curtain separates the glass from the firebox. This keeps it clean.

Adjustable feet allow for leveling the insert and leveling the floor.

This model is equipped with a movable exhaust outlet, eliminating the need to purchase additional elbows during installation. The angle of the insert's connection to the chimney can be easily adjusted.

MODERN DESIGN

This insert features a modern, panoramic front with a shallow combustion chamber, making it perfect for small living rooms with low heating requirements. Ideal for energy-efficient and passive homes. The modern solutions used in the fireplace guarantee energy savings and make operation and cleaning hassle-free.

The insert is equipped with a single, decorative glass pane, giving it an elegant and modern look. This solution visually enlarges the front of the insert and highlights the fire.

The insert door has a convenient handle.
