Cast iron fireplace KRATKI ANTEK 10 kW Ø 180 installation kit
Description
Discover the magic of warmth with the ANTEK cast iron fireplace
The ANTEK cast iron fireplace is a modern and efficient heating solution that meets Ecodesign standards, ensuring environmental friendliness and high energy efficiency.
The densely spaced heat sinks in the ANTEK fireplace maximize heat transfer to the room, leading to more efficient and even heating. The hearth walls are made of high quality 8mm thick cast iron, ensuring robust construction, resistance to damage and long-lasting heat retention, increasing the fireplace's efficiency and lowering operating costs.
ANTEK fireplace meets the requirements of Ecodesign
ADVANTAGES
- convenient handle allows easy opening and closing of the fireplace door,
- the front of the insert is equipped with heat-resistant ceramics that can withstand temperatures up to 600°C,
- decorative hurdle makes it easy to keep the use clean and prevents wood from falling out,
- an ash drawer that collects the remains of burnt wood and a movable grate that facilitates the removal of ashes,
- reduced soot deposition thanks to the clean glass system (air guide),
- maximum heat utilization thanks to densely spaced heat sinks and hearth walls made of high quality 8 mm thick cast iron,
- afterburning of fuel particles thanks to a deflector that extends the flue gas path,
- increased efficiency of the insert's operation through manual adjustment of the chimney draught with the use of a built-in shaft,
- manual control of the combustion process realized by sliding the ash pan.
The kit includes
- cast iron fireplace insert ANTEK/PF 10 kW - 1 pc.
- base for the insert - 1pc.
- cold air intake - 1pc.
- 90 degree transition from the inlet - 1pc.
- flex fi 125 degrees - 1pc.
- worm clamp - 4pcs.
- intake-pipe transition fi 125 - 1pc.
- throttle with linkage - 1pc.
- steel pipes to connect the chimney: 1meter fi 180 - 1pc.
- steel pipes for chimney connection: 0.5m fi 180 - 1pc.
- movable steel elbow angle 90 degrees, fi 180 - 1pc.
- transition from pipe to ceramic chimney fi 180 to opening fi 200 - 1pc.
- insulation boards for development - 20 pcs.
- pins for fastening boards - 16 pcs.
- max adhesive for insulation boards - 1 pc.
- joint adhesive - 3pcs.
- LUFT SF black 9x60 grid - 1 pc.
- LUFT grid black 9x60 - 2 pcs.
Technical data
Rated output (kW) | 10 |
---|---|
Heating power range (kW) | 4.5 - 13 |
Heating efficiency (%) | 76 |
Exhaust gas temperature (℃) | 300 |
Max length of logs (cm) | 33 |
Min inlet grids active field (cm2) | ≥500 |
Min outlet grids active field (cm2) | ≥700 |
Flue outlet diameter (mm) | 180 |
Color | Black |
Materials | Cast iron |
Door opening direction | Left |
Energy class | A |
---|---|
Energy efficiency index (EEI) | 100.2 |
Seasonal Heating efficiency (%) | 66 |
Thermal power for space heating (kW) | 10 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.135 |
Emisja CO (mg/Nm3) | 1681 |
Dust emission (mg/Nm3) | 22 |
Emisja NOx (mg/Nm3) | 116 |
Emiscja OGC (mg/Nm3) | 80 |
Flue gases mass flow rate (g/s) | 9.1 |
Meets requirements | Ecodesign |
---|
Design features | Air intake - additional option, Ashpan |
---|---|
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5903751040927 |
Width (cm) | 60 |
---|---|
Height (cm) | 62.2 |
Depth (cm) | 33.4 |
Weight (kg) | 225.08 |
