Cast iron fireplace KRATKI ANTEK 10 kW Ø 180
Description
Discover the magic of warmth with the ANTEK cast iron fireplace
The ANTEK cast iron fireplace is a modern and efficient heating solution that meets Ecodesign standards, ensuring environmental friendliness and high energy efficiency.
The densely spaced heat sinks in the ANTEK fireplace maximize heat transfer to the room, leading to more efficient and even heating. The hearth walls are made of high quality 8mm thick cast iron, ensuring robust construction, resistance to damage and long-lasting heat retention, increasing the fireplace's efficiency and lowering operating costs.
ANTEK fireplace meets the requirements of Ecodesign
ADVANTAGES
- convenient handle allows easy opening and closing of the fireplace door,
- the front of the insert is equipped with heat-resistant ceramics that can withstand temperatures up to 600°C,
- decorative hurdle makes it easy to keep the use clean and prevents wood from falling out,
- an ash drawer that collects the remains of burnt wood and a movable grate that facilitates the removal of ashes,
- reduced soot deposition thanks to the clean glass system (air guide),
- maximum heat utilization thanks to densely spaced heat sinks and hearth walls made of high quality 8 mm thick cast iron,
- afterburning of fuel particles thanks to a deflector that extends the flue gas path,
- increased efficiency of the insert's operation through manual adjustment of the chimney draught with the use of a built-in shaft,
- manual control of the combustion process realized by sliding the ash pan.
Comfort of use
Technical data
Version | Front facing |
---|---|
Rated output (kW) | 10 |
Heating power range (kW) | 4.5 - 13 |
Heating efficiency (%) | 76 |
Exhaust gas temperature (℃) | 300 |
Max length of logs (cm) | 33 |
Min inlet grids active field (cm2) | ≥500 |
Min outlet grids active field (cm2) | ≥700 |
Flue outlet diameter (mm) | 180 |
Color | Black |
Self Closure | No |
Materials | Cast iron |
Door opening direction | Left |
Energy class | A |
---|---|
Energy efficiency index (EEI) | 100.2 |
Seasonal Heating efficiency (%) | 66 |
Thermal power for space heating (kW) | 10 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.135 |
Emisja CO (mg/Nm3) | 1681 |
Dust emission (mg/Nm3) | 22 |
Emisja NOx (mg/Nm3) | 116 |
Emiscja OGC (mg/Nm3) | 80 |
Flue gases mass flow rate (g/s) | 9.1 |
Meets requirements | Ecodesign |
---|
Design features | Air intake - additional option, Ashpan |
---|---|
Front type | Cast iron front with ceramic glass |
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5901350038864 |
Width (cm) | 60 |
---|---|
Height (cm) | 62.2 |
Depth (cm) | 33.4 |
