Designations
Sku ZIBI/KONF
Specification
Nominal power (kW) 11
Thermal Efficiency (%) 80
Certificates
- Ecodesign
- Designed for recuperation
- BImSchV 2
KLAMKA/PERFOROWANA/MB/LUCY
SZNUR/W/CZARNY/PODKLEJANY
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Built-in fi 125 external air intake which provides air supply from the outside directly into the hearth which results in better combustion and better comfort of usage.
Regulation of air intake is made by the sliding element which is located at the bottom. This allows for manual dosing of air required for proper combustion.
Reducing emissions of harmful CO to the atmosphere by regulating of secondary air supply.
Maximum usage of heat thanks to densely spaced radiators.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
An elegant and comfortable handle.
It can be used in a various mounting conditions thanks to adjustable legs and movable fumes outlet with 360 regulation.
Technical data
| Version | Front facing |
|---|---|
| Nominal power (kW) | 11 |
| Heating power range (kW) | 4.5 - 14.0 |
| Thermal Efficiency (%) | 80 |
| Flue gas temperature (°C) | 289 |
| Max billet length (cm) | 40 |
| Minimum required active area of inlet grilles (cm2) | ≥700 |
| Minimum required active field of outlet grilles (cm2) | ≥900 |
| diameter of the flue gas outlet | 180 |
| Air intake diameter (mm) | 125 |
| Color | Black |
| Additional closing | No |
| Base material | Steel |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 106 |
| Seasonal Energy Efficiency (%) | 70 |
| Heat output for space heating (kW) | 11 |
| CO emission (at 13% O2) ≤ given in % | 0.096 |
| CO emission (mg/m3) | 1208 |
| Pollen emission (mg/m3) | 38 |
| NOx emission (mg/m3) | 113 |
| OGC emission (mg/m3) | 45 |
| Flue gas mass flow (g/s) | 8.8 |
| Certificates | Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Equipment | Air intake - built in , Combustion chamber lining |
|---|---|
| FRONT | Steel front with ceramic glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Number of pieces in a package. | 2 |
| EAN | 5901350053287 |
| Width (cm) | 76.5 |
|---|---|
| Height (cm) | 87.3 |
| Depth (cm) | 44 |
Customer reviews
5 / 5
Have this product?
Rate Steel fireplace KRATKI ZIBI 11 kW Ø 180 and help others to make a choice.
- Rafał A
The fireplace is well packaged, no visible damage (except for a small dent in the intake pipe). I also purchased additional dedicated feet. After tightening them to the fireplace, you can see that the feet on the ground side "escape" to the center of the fireplace. The difference between the distance between the legs at the point of screwing with the fireplace and at the floor is even 1cm. The fireplace may not fall over, but since you are asking for an opinion, I am writing.
The content of the review was translated automatically. Show original contentKominek dobrze zapakowany, nie widać żadnych uszkodzeń (oprócz niewielkiego wgniecenia rury dolotowej). Zakupiłem również dodatkowe dedykowane nóżki. Po dokręceniu ich do kominka widać, że nóżki od strony podłoża "uciekają" do środka kominka. Różnica odległości pomiędzy nóżkami w miejscu skręcenia z kominkiem, a przy podłodze wynosi nawet 1cm. Kominek może się nie przewróci, ale skoro pytacie o opinię, to piszę.
- O ********D *****
I ordered the fireplace on Thursday on Monday was already in Germany quickly and efficiently. Fireplace visually first class, unfortunately, as to the use at the moment I can not say anything. We will see in the autumn and winter season.
The content of the review was translated automatically. Show original contentZamówiłem kominek w czwartek w poniedziałek był już w Niemczech szybko i sprawnie. Kominek wizualnie pierwsza klasa niestety co do użytkowania na chwile obecna nie mogę nic powiedzieć. Zobaczymy w sezonie jesienno zimowym.
- Sławomir G
Fireplace bought in 2015r I am very happy with it, the glass was cleaned once a year , all the time clean glass, the glass system works, now we have a new house and also in the living room will wrap Zibi
The content of the review was translated automatically. Show original contentKominek kupiony w 2015r jestem z niego bardzo zadowolony, szyba czyszczona była raz na rok , cały czas czysta szyba, system szyby działa, teraz mamy nowy dom i również w salonie zawita Zibi
- I *********D **************
Good quality and workmanship I have been using another cartridge for 12 years and am very satisfied
The content of the review was translated automatically. Show original contentDobra jakość i wykonanie użytkuje 12 lat inny wkład i jestem bardzo zadowolony
- K **********L **********
Fireplace solidly made and aesthetically pleasing. Fast shipping, safely packaged.
The content of the review was translated automatically. Show original contentKominek solidnie wykonany i estetyczny. Szybka wysyłka, bezpiecznie zapakowany.
- Maciej D.
Very good quality product.
Meets all the requirements.
Recommended.The content of the review was translated automatically. Show original contentBardzo dobrej jakości produkt. Spełnia wszystkie wymogi. Polecam.
- A ******C **************
Very good workmanship, great service, fast shipping
The content of the review was translated automatically. Show original contentBardzo dobre wykonanie, świetna obsługa, szybka wysyłka
- Krzysztof S.
Very happy to help with the order. Fast delivery.
The content of the review was translated automatically. Show original contentSehr frojntlihe hilfe bei bestelung. Schnele liferung.
- M ********N *********
Goods as described, very good quality
The content of the review was translated automatically. Show original contentTowar zgodny z opisem, bardzo dobra jakość
- Łukasz D.
Delivery fast contact super recommend
The content of the review was translated automatically. Show original contentDostawa szybko kontakt super polecam
Warranty and returns
Warranty
All products on www.kratki.com are brand new, free from physical and legal defects and have been legally launched on the Polish market. The manufacturer gives a 5-year warranty on the proper functioning of the fireplace stove from the moment of its purchase. Fireplace grates and seals are covered by a guarantee for a period of 1 year from the time of purchasing the fireplace stove. The guarantee does not cover: heat resistant ceramics. The use of the fireplace stove, method of installation to the chimney and operating conditions must be in accordance with the instruction manual.
Returns
A Customer being a Consumer, who has concluded the Sales Contract may rescind thereof within a period of 14 days without giving any reasons. The time limits run for the rescission of the Sales Contract shall commence at the time of acquiring the Goods by the Customer or a third party of their choice, other, however, than a carrier. The representations may be submitted in a form whose template has been published by the Seller at the Online Shop Website.
