Designations
Sku ZIBI/KONF
Specification
Rated output (kW) 11
Heating efficiency (%) 80
Meets requirements
- Ecodesign
- Designed for recuperation
- BImSchV 2
Shipping
Availability 14 days of implementation High Stock: 143
Expected delivery date 03.02 - 07.02
Shipping from £248.73
£31.25Price includes VATRS180/1
Availability: 14 Days
£19.58Price includes VATRS180/05 Availability: 14 Days
£25.41Price includes VATKS180/90/R Availability: 14 Days
£3.54Price includes VATROZETA/SO180 Availability: 14 Days
£32.50Price includes VATPRZ/180 Availability: 14 Days
£36.88Price includes VATPODSTAWA/ZIBI Availability: 14 Days
£35.21Price includes VATLUFT/9/80/45S/C Availability: 14 Days
£35.21Price includes VATLUFT/9/80/45S/C/SF Availability: 14 Days
£32.91Price includes VATKLEJ/MAX Availability: 14 Days
£9.96Price includes VATKLEJ/K-84 Availability: 14 Days
£0.66Price includes VATKOLEK Availability: 14 Days
£67.71Price includes VATBLENDA/100/60/ZIBI Availability: 14 Days
£51.67Price includes VATKOSZ/W Availability: 14 Days
£106.25Price includes VATKOSZ/O Availability: 14 Days
£51.67Price includes VATKOSZ/X Availability: 14 Days
£4.99Price includes VATZAPALARKA/KRATKI.COM Availability: 14 Days
£6.68Price includes VATREWIZJA/15/B Availability: 14 Days
£19.58Price includes VATP125 Availability: 14 Days
£145.83Price includes VATMSK/P125 Availability: 14 Days
£83.33Price includes VATBLENDA70/ZIBI Availability: 14 Days
£81.25Price includes VATBLENDA35/ZIBI Availability: 14 Days
£824.58Price includes VATPAKADAMDW180 Availability: 14 Days
£38.75Price includes VATKLAMKA/PERFOROWANA/MB/LUCY Availability: 14 Days
£2.89Price includes VATSZNUR/W/CZARNY/PODKLEJANY Availability: 14 Days
£1.15Price includes VATSZNUR/W/P/K/10X3 Availability: 14 Days
£0.79Price includes VATSZNUR/W/O/9.5 Availability: 14 Days
£187.05Price includes VATTERMOTEC/ZIBI Availability: 14 Days
£67.71Price includes VATS/4/594X386/ZIBI Availability: 14 Days
£24.59Price includes VATDEFLEKTOR/STAL/ZIBI/MALOWANE Availability: 14 Days
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Built-in fi 125 external air intake which provides air supply from the outside directly into the hearth which results in better combustion and better comfort of usage.
Regulation of air intake is made by the sliding element which is located at the bottom. This allows for manual dosing of air required for proper combustion.
Reducing emissions of harmful CO to the atmosphere by regulating of secondary air supply.
Maximum usage of heat thanks to densely spaced radiators.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
An elegant and comfortable handle.
It can be used in a various mounting conditions thanks to adjustable legs and movable fumes outlet with 360 regulation.
Technical data
| Version | Front facing |
|---|---|
| Rated output (kW) | 11 |
| Heating power range (kW) | 4.5 - 14.0 |
| Heating efficiency (%) | 80 |
| Exhaust gas temperature (℃) | 289 |
| Max length of logs (cm) | 40 |
| Min inlet grids active field (cm2) | ≥700 |
| Min outlet grids active field (cm2) | ≥900 |
| Flue outlet diameter (mm) | 180 |
| Air intake diameter (mm) | 125 |
| Color | Black |
| Self Closure | No |
| Materials | Steel |
| Door opening direction | Left |
| Energy class | A |
|---|---|
| Energy efficiency index (EEI) | 106 |
| Seasonal Heating efficiency (%) | 70 |
| Thermal power for space heating (kW) | 11 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.096 |
| CO emission (mg/m3) | 1208 |
| Dust emission (mg/Nm3) | 38 |
| NOx emission (mg/m3) | 113 |
| OGC emission (mg/m3) | 45 |
| Flue gases mass flow rate (g/s) | 8.7 |
| Meets requirements | Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Design features | Air intake - built in , Combustion chamber lining |
|---|---|
| Front type | Steel front with ceramic glass |
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
| EAN | 5901350053287 |
| Width (cm) | 76.5 |
|---|---|
| Height (cm) | 87.3 |
| Depth (cm) | 44 |
