Recommended products
Designations
Sku NADIA/10/KONF
Specification
Rated output (kW) 10
Heating efficiency (%) 80
Meets requirements
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Shipping
Availability 14 days of implementation Medium Stock: 36
Expected delivery date 03.02 - 07.02
Shipping from £248.73
£77.08Price includes VATBLENDA35/NADIA/10
Availability: 14 Days
£83.33Price includes VATBLENDA70/NADIA/10 Availability: 14 Days
£131.25Price includes VATBLENDA/NADIA/10 Availability: 14 Days
£32.91Price includes VATDOMYKANIE/L/2 Availability: 14 Days
£9.96Price includes VATKLEJ/K-84 Availability: 14 Days
£32.91Price includes VATKLEJ/MAX Availability: 14 Days
£0.66Price includes VATKOLEK Availability: 14 Days
£106.25Price includes VATKOSZ/O Availability: 14 Days
£51.67Price includes VATKOSZ/W Availability: 14 Days
£51.67Price includes VATKOSZ/X Availability: 14 Days
£26.88Price includes VATKS200/90/R Availability: 14 Days
£202.09Price includes VATMSK/GLASS/P125 Availability: 14 Days
£0.95Price includes VATOPASKA/SLIMAKOWA Availability: 14 Days
£713.34Price includes VATPAK2200 Availability: 14 Days
£905.62Price includes VATPAKADAMDW200 Availability: 14 Days
£38.95Price includes VATPODSTAWA/NADIA/PF Availability: 14 Days
£32.50Price includes VATPRZ/200 Availability: 14 Days
£6.68Price includes VATREWIZJA/15/B Availability: 14 Days
£3.96Price includes VATROZETA/SO200 Availability: 14 Days
£16.25Price includes VATRS200/025 Availability: 14 Days
£19.58Price includes VATRS200/05 Availability: 14 Days
£4.99Price includes VATZAPALARKA/KRATKI.COM Availability: 14 Days
£2.89Price includes VATSZNUR/W/CZARNY/PODKLEJANY Availability: 14 Days
£1.04Price includes VATSZNUR/W/P/K/10X1 Availability: 14 Days
£1.13Price includes VATSZNUR/W/O/14 Availability: 14 Days
£171.34Price includes VATTERMOTEC/NADIA/10 Availability: 14 Days
£9.21Price includes VATLISTWA/GLASS/NADIA/10/LUCY/12 Availability: 14 Days
£237.50Price includes VATS/4/G/607X477/NADIA/10 Availability: 14 Days
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall.
The cleanliness of combustion chamber thanks to hexagonal hearth.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum.
Reduced soot deposition through a system of pure glass (air curtain).
It can be used in a various mounting conditions thanks to adjustable legs and movable fumes outlet with 360 regulation.
Possibillity to change the direction of door opening from a standard left-hand opening to the right-hand opening.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Elegant and comfortable sliding handle.
Technical data
| Version | Front facing |
|---|---|
| Rated output (kW) | 10 |
| Heating power range (kW) | 5.0 - 12.5 |
| Heating efficiency (%) | 80 |
| Exhaust gas temperature (℃) | 255 |
| Max length of logs (cm) | 35 |
| Min inlet grids active field (cm2) | ≥700 |
| Min outlet grids active field (cm2) | ≥900 |
| Flue outlet diameter (mm) | 200 |
| Color | Black |
| Self Closure | No |
| Materials | Steel |
| Door opening direction | Left |
| Energy class | A |
|---|---|
| Energy efficiency index (EEI) | 105.4 |
| Thermal power for space heating (kW) | 10 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.1 |
| Dust emission (mg/Nm3) | 32 |
| Meets requirements | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Design features | Air intake - built in , Combustion chamber lining, Decorative glass |
|---|---|
| Front type | Steel front with painted glass |
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
| EAN | 5901350061190 |
| Width (cm) | 68.4 |
|---|---|
| Height (cm) | 121.1 |
| Depth (cm) | 41.8 |
