Recommended products
Designations
Sku MBO/KONF
Specification
Rated output (kW) 15
Heating efficiency (%) 83
Meets requirements KRATKI PRO
Shipping
Availability 14 days of implementation Medium Stock: 13
Expected delivery date 03.02 - 07.02
Shipping from £354.20
Description
MAXIMUM USE OF ENERGY
Made of high quality steel resistant to very high temperatures.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
High flue and smoke tube which are transversely located - increases the area of heat echange between the insert and the surrounding. Reducing the temperature of the gas exhaust helps to increase the efficiency of the device.
Fireplace`s doors resistant to tensions and stable thanks to the use of closed profile. Door seals designed in profiled canal what guarantees proper adherence and protects against ewentual falling out while operating.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air).
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum.
The bottom plate of the insert is significantly reduced relative to the door.
Reduced soot deposition through a system of pure glass (air curtain).
The special perforated design of the handle protects against excessive heating, which has the influence on the high comfort of using the fireplace.
MODERN DESIGN
A fireplace insert with two panes compiled with each other at angles (without brackets).
Decorative, heat-resistant glass that can withstand temperatures up to 660oC. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Doors are equipped with modern handle.
Technical data
| Version | Front facing |
|---|---|
| Rated output (kW) | 15 |
| Heating power range (kW) | 7.0 - 19.0 |
| Heating efficiency (%) | 83 |
| Exhaust gas temperature (℃) | 240 |
| Max length of logs (cm) | 50 |
| Min inlet grids active field (cm2) | ≥700 |
| Min outlet grids active field (cm2) | ≥900 |
| Flue outlet diameter (mm) | 200 |
| Color | Black |
| Self Closure | No |
| Materials | Steel |
| Door opening direction | Left |
| Energy class | A+ |
|---|---|
| Energy efficiency index (EEI) | 109.3 |
| Thermal power for space heating (kW) | 15 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.09 |
| Dust emission (mg/Nm3) | 30 |
| Meets requirements | KRATKI PRO |
|---|
| Design features | Combustion chamber lining |
|---|---|
| Front type | Steel front with painted glass |
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
| EAN | 5901350071311 |
| Width (cm) | 83 |
|---|---|
| Height (cm) | 144 |
| Depth (cm) | 47.3 |
Customer reviews
5 / 5
Have this product?
Rate Steel fireplace KRATKI MBO 15 kW Ø 200 and help others to make a choice.
-
Jakub Everything was fine and as described. The support then worked very well in English. It was not really possible to have a conversation in German.
About the product itself: Looks great and robust. Delivery was on time. Will be installed this weekend, but shouldn't be a problem!
I am personally very satisfied with the advice and service from KRATKI!
Price/performance was TOP!The content of the review was translated automatically. Show original contentAlles bestens und wie beschrieben. Der Support hat dann auf Englisch sehr gut funktioniert. Auf Deutsch konnte man sich so nicht wirklich unterhalten. Zum Produkt selbst: Sieht toll und robust aus. Lieferung erfolgte zeitgemäß. Wird dieses Wochenende installiert,sollte aber kein Problem sein! Ich persönlich bin sehr zufrieden mit der Beratung und dem Service mit der Firma KRATKI! Preis/Leistung war TOP!
- Robert Z.
Workmanship bd. The fit of the ceramics can be improved, unless it was only me.
The content of the review was translated automatically. Show original contentJakość wykonania bd. ,można poprawić spasowanie ceramiki , chyba ,że tylko mi się tak trafiło
- Sebastian K.
very pleased
- Szczepan P.
very pleased
- Katarzyan M.
very pleased
Warranty and returns
Warranty
All products on www.kratki.com are brand new, free from physical and legal defects and have been legally launched on the Polish market. The manufacturer gives a 5-year warranty on the proper functioning of the fireplace stove from the moment of its purchase. Fireplace grates and seals are covered by a guarantee for a period of 1 year from the time of purchasing the fireplace stove. The guarantee does not cover: heat resistant ceramics. The use of the fireplace stove, method of installation to the chimney and operating conditions must be in accordance with the instruction manual.
Returns
A Customer being a Consumer, who has concluded the Sales Contract may rescind thereof within a period of 14 days without giving any reasons. The time limits run for the rescission of the Sales Contract shall commence at the time of acquiring the Goods by the Customer or a third party of their choice, other, however, than a carrier. The representations may be submitted in a form whose template has been published by the Seller at the Online Shop Website.
