Designations
Sku MBA/KONF
Specification
Rated output (kW) 17
Heating efficiency (%) 80
Meets requirements
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Shipping
Availability 14 days of implementation Medium Stock: 5
Expected delivery date 03.02 - 07.02
Shipping from £355.12
£131.25Price includes VATBLENDA/MBA
Availability: 14 Days
£32.91Price includes VATDOMYKANIE/L/7 Availability: 14 Days
£106.25Price includes VATKOSZ/O Availability: 14 Days
£51.67Price includes VATKOSZ/W Availability: 14 Days
£51.67Price includes VATKOSZ/X Availability: 14 Days
£905.62Price includes VATPAKADAMDW200 Availability: 14 Days
£10.04Price includes VATLISTWA/GLASS/MBO V2 Availability: 14 Days
£302.09Price includes VATS/4/G/686X536/MB-A/SS Availability: 14 Days
£293.44Price includes VATTERMOTEC/MB-A Availability: 14 Days
£1.13Price includes VATSZNUR/W/O/14 Availability: 14 Days
£1.04Price includes VATSZNUR/W/P/K/10X1 Availability: 14 Days
£2.89Price includes VATSZNUR/W/CZARNY/PODKLEJANY Availability: 14 Days
£38.75Price includes VATKLAMKA/PERFOROWANA/MB/LUCY Availability: 14 Days
Description
MAXIMUM USE OF ENERGY
Made of high quality steel resistant to very high temperatures.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
High flue and smoke tube which are transversely located - increases the area of heat echange between the insert and the surrounding. Reducing the temperature of the gas exhaust helps to increase the efficiency of the device.
Fireplace`s doors resistant to tensions and stable thanks to the use of closed profile. Door seals designed in profiled canal what guarantees proper adherence and protects against ewentual falling out while operating.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air).
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660oC.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum. The bottom plate of the insert is significantly reduced relative to the door.
Reduced soot deposition through a system of pure glass (air curtain).
The special perforated design of the handle protects against excessive heating, which has the influence on the high comfort of using the fireplace.
MODERN DESIGN
A fireplace insert with two panes compiled with each other at angles (without brackets).
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Doors are equipped with modern handle.
Technical data
| Version | Front facing |
|---|---|
| Rated output (kW) | 17 |
| Heating power range (kW) | 8.0 - 21.0 |
| Heating efficiency (%) | 80 |
| Exhaust gas temperature (℃) | 250 |
| Max length of logs (cm) | 50 |
| Min inlet grids active field (cm2) | ≥800 |
| Min outlet grids active field (cm2) | ≥1000 |
| Flue outlet diameter (mm) | 200 |
| Color | Black |
| Self Closure | No |
| Materials | Steel |
| Door opening direction | Left |
| Energy class | A |
|---|---|
| Energy efficiency index (EEI) | 105.4 |
| Thermal power for space heating (kW) | 17 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.09 |
| Dust emission (mg/Nm3) | 35 |
| Meets requirements | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Design features | Air intake - built in , Combustion chamber lining, Decorative glass |
|---|---|
| Front type | Steel front with painted glass |
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
| EAN | 5901350071885 |
| Width (cm) | 83 |
|---|---|
| Height (cm) | 150 |
| Depth (cm) | 47.5 |
