Designations
Sku MB120/KONF
Specification
Nominal power (kW) 20
Thermal Efficiency (%) 80
Certificates
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
TANGO2/CZARNY/TUV
NIT/ZRYWALNY/3X8/ISO15977/AL/ST
NAKRETKA/M8/DIN439/KL8/OCYNK
SRUBA/M8X35/DIN7991/10.9/CZERNIONA
SRUBA/M6X14/DIN7991/10.9/CZERNIONA
SRUBA/M6X12/DIN7991/10.9/CZERNIONA
SRUBA/M6X10/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X8/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X12/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X10/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X10/DIN912/8.8/CZERNIONA
SRUBA/M4X8/ISO7380-2/10.9/CZERNIONA
PODKLADKA/8/DIN125/OCYNK
PODKLADKA/6/DIN125/OCYNK
PODKLADKA/B8/DIN137B/CZERNIONA
PODKLADKA/B6/DIN137B/CZERNIONA
S/4/G/1155X384/MB-120/G/SS
SZNUR/W/CZARNY/PODKLEJANY
SPREZYNA/FI8/4MM/CZERNIONA
SRUBA/M5X16/DIN7991/10.9/CZERNIONA
SRUBA/M5X12/DIN7991/10.9/CZERNIONA
KLAMKA/MBAO/NADIA/12/13/14LP/G/MALOWANA
Description
MAXIMUM USE OF ENERGY
Made of high quality steel resistant to very high temperatures.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
High flue and smoke tube which are transversely located - increases the area of heat echange between the insert and the surrounding. Reducing the temperature of the gas exhaust helps to increase the efficiency of the device.
Fireplace`s doors resistant to tensions and stable thanks to the use of closed profile. Door seals designed in profiled canal what guarantees proper adherence and protects against ewentual falling out while operating.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air).
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum.
Reduced soot deposition through a system of pure glass (air curtain).
Double door opening system - lift up (Guillotine) and side opening. Lifted door makes loading of wood easier and machanism of side door opening allows to clean the glass.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Technical data
| Version | Simple guillotine |
|---|---|
| Nominal power (kW) | 20 |
| Heating power range (kW) | 10.0 - 27.0 |
| Thermal Efficiency (%) | 80 |
| Flue gas temperature (°C) | 240 |
| Optimal log length (mm) | 350 |
| Max billet length (cm) | 50 |
| Minimum required active area of inlet grilles (cm2) | ≥800 |
| Minimum required active field of outlet grilles (cm2) | ≥1000 |
| diameter of the flue gas outlet | 200 |
| Air intake diameter (mm) | 125 |
| Color | Black |
| Additional closing | No |
| Door opening | Up |
| Energy class | A |
|---|---|
| EEI | 105 |
| Seasonal Energy Efficiency (%) | 70 |
| Heat output for space heating (kW) | 20 |
| CO emission (at 13% O2) ≤ given in % | 0.096 |
| CO emission (mg/m3) | 1202 |
| Pollen emission (mg/m3) | 11 |
| NOx emission (mg/m3) | 138 |
| OGC emission (mg/m3) | 17 |
| Flue gas mass flow (g/s) | 20.8 |
| Certificates | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Equipment | Air intake - built in , Combustion chamber lining, Decorative glass |
|---|---|
| FRONT | Steel front with painted glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Number of pieces in a package. | 1 |
| EAN | 5901350079966 |
| Width (cm) | 145.4 |
|---|---|
| Height (cm) | 136.3 |
| Depth (cm) | 56 |
