Recommended products
Designations
Sku MBN/L/BS/Z/MSK/GLASS
Specification
Rated output (kW) 8
Heating efficiency (%) 80
Meets requirements
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Weight (kg) 159.97
Shipping
Availability 1 day of implementation Low stock
Expected delivery date 21.01 - 27.01
Shipping from £355.12
Description
INTELLIGENT FIREPLACE WITH MSK CONTROL GLASS
Save money and the environment with the electronically operated fireplace insert MBN.
The MSK GLASS controlled fireplace insert is the latest development in the field of intelligent fireplaces.
Thanks to automatic control of the burning process we can save up to 30% of wood - you save money and the environment.
It is also very important that in case of power failure the electronic damper is set in the open position allowing you to return to the manual control of the combustion process.
The device meets the requirements of Ecodesign and the BImSchV 2 standard for maximum CO emissions.
It is equipped with a single, decorative glass pane that makes it look elegant and modern. The application of this solution optically enlarges the front of the insert and emphasizes the vision of the fire.
CONTROLLER FUNCTIONS
Precise dosage of air for combustion.
Room temperature control - when the temperature set on the controller is reached, the damper automatically closes the supply of oxygen to the furnace so that the combustion process is slower.
Protection against overheating.
THE KIT INCLUDES
MSK GLASS microprocessor controller.
Temperature sensor with 2.5 m silicone cable.
Electronic throttle.
Flush box.
Technical data
| Rated output (kW) | 8 |
|---|---|
| Heating power range (kW) | 4.0 - 11.0 |
| Heating efficiency (%) | 80 |
| Exhaust gas temperature (℃) | 255 |
| Max length of logs (cm) | 30 |
| Min inlet grids active field (cm2) | ≥500 |
| Min outlet grids active field (cm2) | ≥700 |
| Flue outlet diameter (mm) | 200 |
| Materials | Steel |
| Door opening direction | Left |
| Energy class | A |
|---|---|
| Energy efficiency index (EEI) | 105.4 |
| Thermal power for space heating (kW) | 8 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.1 |
| Dust emission (mg/Nm3) | 21 |
| Meets requirements | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
|---|---|
| EAN | 5903751130796 |
| Width (cm) | 59.2 |
|---|---|
| Height (cm) | 116 |
| Depth (cm) | 54.7 |
| Weight (kg) | 159.97 |
Customer reviews
Warranty and returns
Warranty
All products on www.kratki.com are brand new, free from physical and legal defects and have been legally launched on the Polish market. The manufacturer gives a 5-year warranty on the proper functioning of the fireplace stove from the moment of its purchase. Fireplace grates and seals are covered by a guarantee for a period of 1 year from the time of purchasing the fireplace stove. The guarantee does not cover: heat resistant ceramics. The use of the fireplace stove, method of installation to the chimney and operating conditions must be in accordance with the instruction manual.
Returns
A Customer being a Consumer, who has concluded the Sales Contract may rescind thereof within a period of 14 days without giving any reasons. The time limits run for the rescission of the Sales Contract shall commence at the time of acquiring the Goods by the Customer or a third party of their choice, other, however, than a carrier. The representations may be submitted in a form whose template has been published by the Seller at the Online Shop Website.
