Designations
Sku AMELIA/ECO
Specification
Nominal power (kW) 13
Thermal Efficiency (%) 80
Certificates
- Ecodesign
- BImSchV 2
Weight (kg) 195
Description
MAXIMUM USE OF ENERGY
Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm.
Increased heat exchange surface between the hot exhaust gases and the room due to the high flue.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Increased efficiency of the insert through manual control of chimney draft by using the built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
Reduces CO emissions to the environment thanks to the afterburning system of exhaust fumes (Amelia Eko).
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
SAFETY AT THE HIGHEST LEVEL
Classic front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
CONVENIENT TO USE
The cold handle system which limits the risk of burns due to the possibility of removing it while burning.
Ash drawer / ashtray, where the remains of burnt wood are gathered and grate for easy ash removal.
Reduced soot deposition through a system of pure glass (air curtain).
Technical data
| Nominal power (kW) | 13 |
|---|---|
| Heating power range (kW) | 5.0 - 15.5 |
| Thermal Efficiency (%) | 80 |
| Flue gas temperature (°C) | 235 |
| Optimal log length (mm) | 300 |
| Max billet length (cm) | 40 |
| Minimum required active area of inlet grilles (cm2) | ≥800 |
| Minimum required active field of outlet grilles (cm2) | ≥1000 |
| diameter of the flue gas outlet | 200 |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 106 |
| Seasonal Energy Efficiency (%) | 70 |
| Heat output for space heating (kW) | 13 |
| CO emission (at 13% O2) ≤ given in % | 0.087 |
| CO emission (mg/m3) | 1092 |
| Pollen emission (mg/m3) | 9 |
| NOx emission (mg/m3) | 125 |
| OGC emission (mg/m3) | 82 |
| Flue gas mass flow (g/s) | 12.9 |
| Certificates | Ecodesign, BImSchV 2 |
|---|
| Equipment | Ashpan |
|---|---|
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Number of pieces in a package. | 2 |
| EAN | 5901350036389 |
| Width (cm) | 75 |
|---|---|
| Height (cm) | 92.5 |
| Depth (cm) | 45.5 |
| Weight (kg) | 195 |
