Cast iron fireplace KRATKI WIKTOR 14 kW Ø 200
Description
MAXIMUM USE OF ENERGY
Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Increased efficiency of the insert through manual control of chimney draft by using the built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Classic front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
CONVENIENT TO USE
The cold handle system which limits the risk of burns due to the possibility of removing it while burning.
Ash drawer / ashtray, where the remains of burnt wood are gathered and grate for easy ash removal.
Reduced soot deposition through a system of pure glass (air curtain).
Technical data
Version | Front facing |
---|---|
Rated output (kW) | 14 |
Heating power range (kW) | 6-18 |
Heating efficiency (%) | 80 |
Exhaust gas temperature (℃) | 300 |
Max length of logs (cm) | 45 |
Min inlet grids active field (cm2) | ≥700 |
Min outlet grids active field (cm2) | ≥900 |
Flue outlet diameter (mm) | 200 |
Color | Black |
Self Closure | No |
Materials | Cast iron |
Door opening direction | Left |
Energy class | A |
---|---|
Energy efficiency index (EEI) | 92.35 |
Moc cieplna do ogrzewania pomieszczeń (kW) | 14 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.14 |
Dust emission (mg/Nm3) | 99.7 |
Meets requirements | Ecodesign |
---|
Design features | Air intake - additional option, Ashpan |
---|---|
Front type | Cast iron front with ceramic glass |
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5901350010976 |
Width (cm) | 73.8 |
---|---|
Height (cm) | 64.5 |
Depth (cm) | 38.4 |
Customer reviews
- Katarzyna P.
Efficient with a large glass window. Cast iron holds heat longer than steel, in addition, I encased it with chamotte. For the price it is worth it! Fi 180 can handle, but with a chimney over 8 meters, then it does not dirty the glass. I recommend!
The content of the review was translated automatically. Show original contentWydajny z dużą szybą. Żeliwo dłużej trzyma ciepło niż stal, dodatkowo obudowałem go szamotką. Za tą cenę warto! Fi 180 daje radę, ale przy kominie pow. 8 metrów, wtedy nie brudzi szyby. Polecam!
- Tomasz T.
The quality of workmanship is not objectionable. The external form is well-designed, without the extravagances that are fashionable today, and can fit into any type of interior.
The content of the review was translated automatically. Show original contentJakość wykonania nie budzi zastrzeżeń. Forma zewnętrzna dobrze zaprojektowana, bez modnych dziś ekstrawagancji, może pasować do każdego rodzaju wnętrza.
Warranty and returns
All products on www.kratki.com are brand new, free from physical and legal defects and have been legally launched on the Polish market. The manufacturer gives a 5-year warranty on the proper functioning of the fireplace stove from the moment of its purchase. Fireplace grates and seals are covered by a guarantee for a period of 1 year from the time of purchasing the fireplace stove. The guarantee does not cover: heat resistant ceramics. The use of the fireplace stove, method of installation to the chimney, and operating conditions must be in accordance with the instruction manual.
A Customer being a Consumer, who has concluded the Sales Contract may rescind thereof within a period of 14 days without giving any reasons. The time limits run for the rescission of the Sales Contract shall commence at the time of acquiring the Goods by the Customer or a third party of their choice, other, however, than a carrier. The representations may be submitted in a form whose template has been published by the Seller at the Online Shop Website.
