Cast iron fireplace KRATKI SIMPLE right 8 kW Ø 200 Set 2

SIMPLE 8 Right Fireplace Insert with Side Glass and Installation Set

Catalog Number: ##SIMPLE/M/S/P/BS/ZABUDOWA/2##

Product Information:

• Double-glazed BS-type inserts with a divided glass
• Perfectly fits into the style of modern interiors
• This type of fireplace is often chosen for open spaces
• Standard features include:
• ENERGY CLASS A
• CLEAN GLASS SYSTEM
• GRATE
• FLUE DAMPER
• ASH PAN
• DEFLECTOR
• DENSELY ARRANGED RADIATORS
• Heating power range from 3 to 10 kW
• High efficiency of up to 80%
• The front glass can withstand up to 660°C
• Installation set for installing the fireplace in the house

We offer various models of these inserts in our auctions.

THE SET INCLUDES:

1. SIMPLE cast iron fireplace insert - 1 pc.
2. Air intake - 1 pc.
3. Flex 125-degree pipe - 1 pc.
4. Base for the insert - 1 pc.
5. Steel pipe for chimney connection: 0.25 meters, Ø 200 - 1 pc.
6. Steel pipe for chimney connection: 0.5 meters, Ø 200 - 1 pc.
7. Movable steel elbow, 90-degree angle, Ø 200 - 1 pc.
8. Transition from pipe to ceramic chimney, Ø 200 - 1 pc.
9. Damper with linkage - 1 pc.
10. Insulation plates - 5 pcs.
11. Max adhesive for insulation plates - 1 pc.
12. LUFT SF left corner black 76.6x54.7x9 - 1 pc.
13. LUFT SF right corner black 54.7x76.6x9 - 1 pc.
14. Clamps - 4 pcs.

The installation set was used by our installers to create the following fireplace insert setup.

Your fireplace can look like this.

If you want to change or add any elements to the set, you can find a wide range of accessories for fireplaces in our other auctions.

Technical data for the insert:

Nominal power (kW): 8

Heating power range (kW): 3-10

Flue diameter (mm): 200

Thermal efficiency (%): 80

CO emission (at 13% O₂) ≤: 0.10%

Dust emission (mg/Nm3): 25

Flue gas temperature °C: 238

Weight (kg): 115

Width (cm): 67.5

Height (cm): 70.1

Depth (cm): 43.3

Max log length (mm): 330

Material: cast iron, steel

Fuel type: recommended seasoned hardwood with moisture ≤20%

BUILT-IN DAMPER

Allows chimney draft regulation, which improves the combustion process efficiency. Regulation is possible with a knob.

ASH PAN DRAWER

Helps keep the insert clean. The knob in front of the drawer allows air intake regulation. Additionally, the grate inside the insert prevents wood from falling out.

DOOR OPENING SYSTEM IN BS-TYPE CORNER INSERTS

The entire door in an L-shape opens for the right corner insert to the right and for the left corner insert to the left.

MODERN DESIGN

Corner fireplace insert with BS-type doors (joined glass), equipped with a single glass.

The insert door has a modern handle.

MAXIMUM ENERGY USE

Fuel particle burnout is achieved through the deflector, which extends the flue gas path. This process also increases combustion efficiency and ensures better energy use, thus minimizing harmful emissions to the atmosphere.

Spacious combustion chamber allows loading a large amount of fuel without frequent refueling.

Manual chimney draft control using the built-in damper.

TOP-TIER SAFETY

The insert front is equipped with heat-resistant ceramic that withstands up to 660°C. The glass offered by us has a quality and safety certificate.

Densely arranged radiators on the outer walls of the unit ensure maximum heat use generated by the insert.

The insert front is resistant to high temperatures due to the use of high-quality steel.

CONVENIENT USE

The unit is equipped with a clean glass system – a so-called air curtain evenly distributes the air flow, sweeping the glass and minimizing soot buildup. This helps maintain the clean and attractive appearance of the glass for a long time.

The removable grate and ash pan make it easier to keep the insert clean.
