Cast iron fireplace KRATKI SIMPLE left 8 kW Ø 200 Set
- Ecodesign
- BImSchV 2
Description
SIMPLE 8 Left Fireplace Insert with Side Glass and Installation Kit
Catalog Number:
Product Information:
Double-sided BS type inserts with divided glass
fits perfectly into the style of modern interiors
this type of fireplace is often chosen for open spaces
standard features:
ENERGY CLASS A
CLEAN GLASS SYSTEM
GRATE
DAMPER
ASH PAN
DEFLECTOR
DENSITY-PLACED RADIATORS
heating power range
from 3 to 10 kW
high
efficiency up to 80%
front glass Withstands
up to 660°C
Fireplace installation kit for your home
We have various models of these inserts on our auctions.
The set includes:
SIMPLE cast iron fireplace insert - 1 pc.
Inlet - 1 pc.
Flex Ø 125 degrees - 1 pc.
Insert base - 1 pc.
Steel pipe for chimney connection: 0.25 meters Ø 200 - 1 pc.
Steel pipe for chimney connection: 0.5 meters Ø 200 - 1 pc.
Movable steel elbow, 90-degree angle, Ø 200 - 1 pc.
Transition from the pipe to the ceramic chimney, hole Ø 200 - 1 pc.
Damper with pull rod 1 pc.
Insulation boards - 10 pcs.
Max glue for insulation boards - 1 pc.
Grid 17x49 graphite - 2 pcs.
Worm-drive clamp 4 pcs.
The assembly kit was used by our installers to complete the fireplace insert installation shown below.
Your fireplace may look like this.
If you want to change or add an element to the kit, you will find a wide selection of fireplace accessories in our other auctions.
Insert specifications:
Nominal power (kW): 8
Heating power range (kW): 3-10
Flue diameter (mm): 200
Thermal efficiency (%): 80
CO Emissions (at 13% O₂) ≤: 0.10%
Particulate Matter Emissions (mg/Nm3): 25
Exhaust Gas Temperature °C: 238
Weight (kg): 115
Width (cm): 67.5
Height (cm): 70.1
Depth (cm): 43.3
Maximum Log Length (mm): 330
Material: cast iron, steel
Fuel Type: Recommended seasoned hardwood with moisture content ≤20%
BUILT-IN CHIMNEY DAMPER
Allows you to regulate chimney draft, which improves combustion efficiency. Adjustment is possible using a knob.
ASH DRAWER
Makes it easier to keep the insert clean. The knob at the front of the drawer allows you to regulate the air flow from the room. Additionally, a fence placed in the insert prevents wood from falling out.
DOOR OPENING SYSTEM FOR BS-TYPE CORNER INSERTS
The entire L-shaped door opens to the right in the right-hand corner insert version, and to the left in the left-hand corner insert version.
MODERN DESIGN
Corner fireplace insert with BS-type doors (combined glass), equipped with a single pane of glass.
The insert door has a modern handle.
MAXIMUM ENERGY USE
Fuel particles are burned thanks to a deflector that extends the exhaust path. This process also increases combustion efficiency and ensures better energy utilization, thus minimizing harmful emissions into the atmosphere.
A spacious combustion chamber allows for loading large amounts of fuel without the need for frequent refills.
Manual chimney draft control using the built-in damper.
HIGHEST LEVEL SAFETY
The front of the insert is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C. The glass we offer is certified for quality and safety.
Densely spaced heat sinks on the outer walls of the device guarantee maximum utilization of the heat generated by the insert.
The front of the insert is resistant to high temperatures thanks to the use of high-quality steel.
COMFORTABLE USE
The device is equipped with a clean glass system - thanks to the so-called curtain, the air flow is distributed evenly, sweeping the glass, and minimizing soot buildup. This allows the glass to maintain an attractive and clean appearance for a long time.
The removable grate and ash pan make it easy to keep the insert clean.
Technical data
| Nominal power (kW) | 8 |
|---|---|
| Thermal Efficiency (%) | 80.1 |
| Flue gas temperature (°C) | 233 |
| Max billet length (cm) | 33 |
| diameter of the flue gas outlet | 200 |
| Base material | Cast iron |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 106 |
| Seasonal Energy Efficiency (%) | 70 |
| Heat output for space heating (kW) | 8 |
| CO emission (at 13% O2) ≤ given in % | 0.094 |
| CO emission (mg/m3) | 1176 |
| Pollen emission (mg/m3) | 17 |
| NOx emission (mg/m3) | 109 |
| OGC emission (mg/m3) | 55 |
| Flue gas mass flow (g/s) | 8.5 |
| Certificates | Ecodesign, BImSchV 2 |
|---|
| Equipment | Air intake - additional option, Ashpan |
|---|---|
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| EAN | 5903751028451 |
| Width (cm) | 67.5 |
|---|---|
| Height (cm) | 70.1 |
| Depth (cm) | 43.3 |
| Weight (kg) | 175.33 |
