Cast iron fireplace KRATKI SIMPLE left 8 kW Ø 200 installation kit

Designations
Sku SIMPLE/M/S/L/BS/ZESTAW/MONTAZOWY
Specification
Nominal power (kW) 8
Thermal Efficiency (%) 80.1
Certificates
  • Ecodesign
  • BImSchV 2
Weight (kg) 237.66

Description

SIMPLE 8 Left Fireplace Insert with Side Glass and Mounting Kit

Catalog Number: ##SIMPLE/M/S/L/BS/ZESTAW/ASSEMBLY##

Product Information:

Double-sided glazed BS type inserts with divided glass

Fit perfectly in the style of modern interiors

This type of fireplace is often chosen for open spaces

Standard: The fireplace has:

ENERGY CLASS A

CLEAN GLASS SYSTEM

GRATE

DAMPER

ASH PAN

DEFLECTOR

DENSITY ARRANGE RADIATORS

Heating power range from 3 to 10 kW

High efficiency up to 80%

Front glass withstands up to 660°C

Fireplace installation kit

We have various models of these inserts on our auctions.

THE KIT INCLUDES:

SIMPLE cast iron fireplace insert - 1 pc.

Inlet - 1 pc.

Flex Ø 125 degrees - 1 pc.

Insert base - 1 pc.

Steel pipe for chimney connection: 0.25 meters Ø 200 - 1 pc.

Steel pipe for chimney connection: 0.5 meters Ø 200 - 1 pc.

Movable steel elbow, 90-degree angle, Ø 200 - 1 pc.

Transition from pipe to ceramic chimney, Ø 200 hole - 1 pc.

Damper with rod 1 pc.

Insulation boards - 10 pcs.

Max glue for insulation boards - 1 pc.

LUFT SF left corner black 76.6x54.7x9 - 1 pc.

LUFT SF right corner black 54.7x76.6x9 - 1 pc.

Worm-drive clamp 4 pcs.

The installation kit was used by our installers to complete the following liner installation. fireplace insert.

Your fireplace can look like this.

If you want to change or add an element to the set, you will find a wide selection of fireplace accessories in our other auctions.

Insert specifications:

Nominal power (kW): 8

Heating power range (kW): 3-10

Flue diameter (mm): 200

Thermal efficiency (%): 80

CO emissions (at 13% O₂) ≤: 0.10%

Particulate matter emissions (mg/Nm3): 25

Exhaust gas temperature °C: 238

Weight (kg): 115

Width (cm): 67.5

Height (cm): 70.1

Depth (cm): 43.3

Maximum log length (mm): 330

Material: cast iron, steel

Fuel type: recommended seasoned hardwood with moisture content ≤20%

BUILT-IN DAMPER

Allows you to regulate chimney draft, which results in a more efficient combustion process. Adjustment is possible using a knob.

ASH DRAWER

Makes it easier to keep the insert clean. The knob at the front of the drawer allows you to regulate the air flow from the room. Additionally, a fence placed in the insert prevents wood from falling out.

DOOR OPENING SYSTEM FOR BS-TYPE CORNER INSERTS

The entire L-shaped door opens to the right in the right-hand corner insert version, and to the left in the left-hand corner insert version.

MODERN DESIGN

Corner fireplace insert with BS-type doors (combined glass), equipped with a single pane of glass.

The insert door has a modern handle.

MAXIMUM ENERGY USE

Fuel particles are burned thanks to a deflector that extends the exhaust path. This process also increases combustion efficiency and ensures better energy utilization, thus minimizing harmful emissions into the atmosphere.

A spacious combustion chamber allows for loading large amounts of fuel without the need for frequent refills.

Manual chimney draft control using the built-in damper.

HIGHEST LEVEL SAFETY

The front of the insert is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C. The glass we offer is certified for quality and safety.

Densely spaced heat sinks on the outer walls of the device guarantee maximum utilization of the heat generated by the insert.

The front of the insert is resistant to high temperatures thanks to the use of high-quality steel.

COMFORTABLE USE

The device is equipped with a clean glass system - thanks to the so-called curtain, the air flow is distributed evenly, sweeping the glass, and minimizing soot buildup. This allows the glass to maintain an attractive and clean appearance for a long time.

The removable grate and ash pan make it easy to keep the insert clean.

Technical data

General data
Nominal power (kW)8
Heating power range (kW)3.0 - 10.0
Thermal Efficiency (%)80.1
Flue gas temperature (°C)233
Max billet length (cm)33
Minimum required active area of inlet grilles (cm2)≥500
Minimum required active field of outlet grilles (cm2)≥700
diameter of the flue gas outlet200
ColorBlack
Base materialCast iron
Door openingLeft
Energetic efficiency
Energy classA
EEI106
Seasonal Energy Efficiency (%)70
Heat output for space heating (kW)8
CO emission (at 13% O2) ≤ given in %0.094
CO emission (mg/m3)1176
Pollen emission (mg/m3)17
NOx emission (mg/m3)109
OGC emission (mg/m3)55
Flue gas mass flow (g/s)8.5
Certifications / Compliance
CertificatesEcodesign, BImSchV 2
Additional information
EquipmentAir intake - additional option, Ashpan
Fuel typeSeasoned deciduous wood (humidity ≤20%)
Number of pieces in a package.2
EAN5903751028475
Physical parameters
Width (cm)67.5
Height (cm)70.1
Depth (cm)43.3
Weight (kg)237.66
