Cast iron fireplace KRATKI AMELIA DECO right 21 kW Ø 200
Description
MAXIMUM USE OF ENERGY
Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm.
Increased heat exchange surface between the hot exhaust gases and the room due to the high flue.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Increased efficiency of the insert through manual control of chimney draft by using the built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
Fireplace`s doors resistant to tensions and stable thanks to the use of closed profile. Door seals designed in profiled canal what guarantees proper adherence and protects against ewentual falling out while operating.
CONVENIENT TO USE
Large combustion chamber, which allows to load a large quantity of fuel without the need for frequent refills.
Reduced soot deposition through a system of pure glass (air curtain).
An elegant and comfortable handle.
The possibility of levelling the fireplace insert thanks to the adjustable legs.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Frame and door of the fireplace made of steel intended to work at elevated temperatures.
A fireplace insert with two panes compiled with each other at angles (without brackets).
Technical data
Version | Corner right |
---|---|
Rated output (kW) | 21 |
Heating power range (kW) | 10 - 25 |
Heating efficiency (%) | 79.9 |
Exhaust gas temperature (℃) | 322 |
Max length of logs (cm) | 50 |
Min inlet grids active field (cm2) | ≥800 |
Min outlet grids active field (cm2) | ≥1000 |
Flue outlet diameter (mm) | 200 |
Color | Black |
Self Closure | No |
Materials | Steel, Cast iron |
Door opening direction | Right |
Energy class | A |
---|---|
Energy efficiency index (EEI) | 106 |
Seasonal Heating efficiency (%) | 70 |
Thermal power for space heating (kW) | 21 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.134 |
CO emission (mg/m3) | 1675 |
Dust emission (mg/Nm3) | 16 |
NOx emission (mg/m3) | 102 |
OGC emission (mg/m3) | 82 |
Flue gases mass flow rate (g/s) | 13.7 |
Meets requirements | Ecodesign |
---|
Design features | Air intake - additional option, Ashpan, Decorative glass |
---|---|
Front type | Steel front with painted glass |
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5901350006061 |
Width (cm) | 80.23 |
---|---|
Height (cm) | 106.5 |
Depth (cm) | 49.1 |
Weight (kg) | 211 |
