Designations
Sku ZUZIA/PW/15/W/DECO
Specification
Nominal power (kW) 12
Thermal Efficiency (%) 81
Certificates
- Ecodesign
- BImSchV 2
Weight (kg) 182
KLAMKA/PERFOROWANA/MB/LUCY
SZNUR/W/CZARNY/PODKLEJANY
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Built in smoke tubes and high flue, which increase the heat exchange surface.
Increased heat exchange surface due to built-in smoke tubes and high flue.
Regulation of chimney draft using built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Protection against overheating by the built-in coil pipe - connector input / output 1/2”.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
Movable grate and ashpan enables to clean the insert.
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Technical data
| Nominal power (kW) | 12 |
|---|---|
| Heating power range (kW) | 5.0 - 15.0 |
| Thermal Efficiency (%) | 81 |
| Max working pressure (bar) | 2 |
| Water capacity (l) | 38 |
| Flue gas temperature (oC) | 254 |
| Max billet length (cm) | 40 |
| Minimum required active field of outlet grilles (cm2) | 240 |
| Minimum required active area of inlet grilles (cm2) | 120 |
| Door opening | Left |
| Base material | Steel, Cast iron |
| Additional closing | No |
| diameter of the flue gas outlet | 200 |
| Energy class | A |
|---|---|
| Average power from water (kW) | 8 |
| Heat output for space heating (kW) | 4 |
| Seasonal Energy Efficiency (%) | 71 |
| CO emission (mg/m3) | 1087 |
| NOx emission (mg/m3) | 108 |
| OGC emission (mg/m3) | 68 |
| EEI | 106 |
| Pollen emission (mg/m3) | 33 |
| CO emission (at 13% O2) ≤ given in % | 0.086 |
| Certificates | Ecodesign, BImSchV 2 |
|---|
| EAN | 5901350062753 |
|---|---|
| Equipment | Ashpan, Combustion chamber lining, Decorative glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 65.2 |
|---|---|
| Height (cm) | 86.9 |
| Depth (cm) | 48.9 |
| Weight (kg) | 182 |
