Designations
Sku ZUZIA/PW/15/W
Specification
Rated output (kW) 12
Heating efficiency (%) 81
Meets requirements
- Ecodesign
- BImSchV 2
Weight (kg) 160
Shipping
Availability 1 day of implementation Medium Stock: 7
Expected delivery date 15.11 - 18.11
Shipping from €70.40
€60.79Net priceDOMYKANIE/L/6
Availability: 14 Days
€825.73Net pricePAKADAMDW200 Availability: 1 Day
€17.48Net priceDOLOT/ZELIWO/100 Availability: 1 Day
€17.48Net priceDOLOT/ZELIWO/125 Availability: 1 Day
€37.61Net pricePODSTAWA/Z/E Availability: 1 Day
€29.63Net pricePRZ/200 Availability: 1 Day
€3.58Net priceROZETA/SO200 Availability: 1 Day
€0.86Net priceOPASKA/SLIMAKOWA Availability: 1 Day
€6.22Net pricePDR90/125 Availability: 1 Day
€3.80Net priceDOLOT/PRZEJSCIE/360 Availability: 1 Day
€30.01Net priceKLEJ/MAX Availability: 1 Day
€9.08Net priceKLEJ/K-84 Availability: 1 Day
€0.61Net priceKOLEK Availability: 1 Day
€6.09Net priceREWIZJA/15/B Availability: 1 Day
€4.56Net priceZAPALARKA/KRATKI.COM Availability: 1 Day
€184.26Net priceMSK/GLASS/P125 Availability: 1 Day
€86.75Net priceNWO/U Availability: 1 Day
€453.99Net priceZPW2K15/U Availability: 14 Days
€42.51Net priceSVH25-1 Availability: 1 Day
€9.60Net priceSVH/E25-1/2 Availability: 1 Day
€1.04Net priceSZNUR/W/P/K/10X3 Availability: 1 Day
€21.08Net price426-A-10009/MALOWANE Availability: 14 Days
€49.58Net price426-A-10007/OBR/W/G/MALOWANE Availability: 14 Days
€38.94Net price426-A-10005/1/MALOWANE Availability: 14 Days
€53.38Net priceS/4/544X393/ZUZIA Availability: 1 Day
€16.91Net priceSZUFLADA/ZUZIA/OLIWIA/AMELIA Availability: 1 Day
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Built in smoke tubes and high flue, which increase the heat exchange surface.
Increased heat exchange surface due to built-in smoke tubes and high flue.
Regulation of chimney draft using built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Protection against overheating by the built-in coil pipe - connector input / output 1/2”.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Classic front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
The cold handle system which limits the risk of burns due to the possibility of removing it while burning.
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
Movable grate and ashpan enables to clean the insert.
Technical data
| Rated output (kW) | 12 |
|---|---|
| Heating power range (kW) | 5.0 - 15.0 |
| Heating efficiency (%) | 81 |
| Max working pressure (bar) | 2 |
| Water capacity (l) | 38 |
| Exhaust gas temperature (℃) | 255 |
| Max length of logs (cm) | 50 |
| Min outlet grids active field (cm2) | 240 |
| Min inlet grids active field (cm2) | 120 |
| Door opening direction | Left |
| Materials | Steel, Cast iron |
| Self Closure | No |
| Flue outlet diameter (mm) | 200 |
| Energy class | A |
|---|---|
| Average power from water (kW) | 8 |
| Thermal power for space heating (kW) | 4 |
| Energy efficiency index (EEI) | 106.7 |
| Dust emission (mg/Nm3) | 33 |
| CO emissions (at 13% O 2 ) ≤ given in % | 0.09 |
| Meets requirements | Ecodesign, BImSchV 2 |
|---|
| EAN | 5901350026205 |
|---|---|
| Design features | Ashpan |
| Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 65.2 |
|---|---|
| Height (cm) | 86.9 |
| Depth (cm) | 49.6 |
| Weight (kg) | 160 |
