Designations
Sku MBA/PW/17/G/W/BLACK
Specification
Nominal power (kW) 17
Thermal Efficiency (%) 86
Certificates
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Weight (kg) 414.5
TERMOTEC/MB-A/BLACK
SZNUR/W/CZARNY/PODKLEJANY
S/4/G/708X516/MB-A/G/SS
KLAMKA/MBAO/NADIA/12/13/14LP/G/MALOWANA
Description
MAXIMUM ENERGY UTILIZATION
Made of high-quality steel, the body and front are resistant to very high temperatures.
Efficient combustion and longer heat retention thanks to the combustion chamber lined with TERMOTEC – a heat-accumulating material that increases the temperature inside the chamber.
A special water jacket system allows heat recovery from the flue gases and transfers it to the heating system, ensuring high energy efficiency of the insert.
Built-in coil. The water jacket body is reinforced with pins. Inlet/outlet connection 1/2.
Stable and stress-resistant fireplace doors made of closed profile. The door gasket is placed in a profiled channel, ensuring proper adhesion and preventing it from falling out during operation.
Two-deflector system that extends the flue gas path, making combustion more ecological.
Air supplied exclusively from the outside through a built-in 125 mm air inlet with damper. Regulation via a single controller, eliminating errors from improper use.
Triple air supply system: primary air directed to the combustion plate; secondary air supplied through openings in the back wall. Additionally, a clean glass system (air curtain) is used.
SAFETY AT THE HIGHEST LEVEL
Excellent tightness thanks to solid welds made in a noble gas shield.
Steel elements laser-cut using modern equipment and bent on CNC presses.
The insert front is equipped with heat-resistant ceramic that withstands up to 660°C.
CONVENIENT USE
Grate-free insert – combustion on ash, meaning fuel burns down to fine ash with minimal residue. Heat energy is maximized. The bottom plate is significantly lowered relative to the door.
Lift-up door system – glass rises upwards, based on counterweights with steel cables running on bearing wheels, ensuring smooth, quiet, and reliable operation. Doors move a few millimeters from the body, protecting the seal. When closed, they are pressed tightly into the frame, ensuring airtightness.
Thanks to lift-up and drop-down doors, larger wood loads can be inserted. An additional mechanism allows side opening of the glass for easy cleaning.
Soot build-up is reduced thanks to the clean glass system (air guide).
MODERN DESIGN
Decorative glass pane resistant up to 660°C, giving the fireplace a modern and elegant appearance while optically enlarging the insert front.
Technical data
| Nominal power (kW) | 17 |
|---|---|
| Heating power range (kW) | 9.0 - 19.5 |
| Thermal Efficiency (%) | 86 |
| Max working pressure (bar) | 2 |
| Water capacity (l) | 47 |
| Flue gas temperature (oC) | 196 |
| Max billet length (cm) | 50 |
| Minimum required active field of outlet grilles (cm2) | 480 |
| Minimum required active area of inlet grilles (cm2) | 240 |
| Door opening | Up |
| Base material | Steel |
| Additional closing | No |
| diameter of the flue gas outlet | 200 |
| Energy class | A+ |
|---|---|
| Average power from water (kW) | 9 |
| Heat output for space heating (kW) | 8 |
| Seasonal Energy Efficiency (%) | 76 |
| CO emission (mg/m3) | 1112 |
| NOx emission (mg/m3) | 123 |
| OGC emission (mg/m3) | 66 |
| EEI | 113 |
| Pollen emission (mg/m3) | 8 |
| CO emission (at 13% O2) ≤ given in % | 0.089 |
| Certificates | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| EAN | 5901350031285 |
|---|---|
| Equipment | Air intake - built in , Combustion chamber lining, Decorative glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 96.5 |
|---|---|
| Height (cm) | 142.9 |
| Depth (cm) | 53.7 |
| Weight (kg) | 414.5 |
