Designations
Sku LUCY/PW/12/W/DG
Specification
Nominal power (kW) 12
Thermal Efficiency (%) 82
Certificates
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Weight (kg) 215
BLENDA/100/60/LUCY/12
KLAMKA/PERFOROWANA/MB/LUCY
SZNUR/W/CZARNY/PODKLEJANY
S/4/568X438/LUCY/12/WEW
07BL-08-00-00/MALOWANE
DEFLEKTOR/DOLNY/STAL/LUCY/12/MALOWANE
LISTWA/GLASS/NADIA/10/LUCY/12
S/4/G/607X477/NADIA/10
Description
MAXIMUM ENERGY USE
The body and front of the insert are resistant to high temperatures thanks to the material used – high-quality steel.
A special water jacket assembly allows for the extraction of a large amount of heat from exhaust gases and transferring it to the heating system, thus achieving high energy efficiency of the insert.
Built-in coil. The water jacket body is reinforced with pins. 1/2" inlet/outlet connector.
Efficient combustion and longer temperature retention thanks to the TERMOTEC combustion chamber lining - a heat-accumulating material that increases the temperature in the chamber.
A system of two deflectors that extend the exhaust gas path makes combustion more ecological.
Exclusively external air supplied thanks to the built-in 125 mm air intake connector. Air intake is adjusted with a single regulator, eliminating errors due to improper use.
Triple combustion chamber ventilation system: primary air - supplied under the grate; secondary air is supplied through holes in the rear wall. Additionally, the insert features a clean glass system (air curtain).
The fireplace is available with double glazing, which improves heat transfer to the room and reduces the risk of the fireplace glass becoming dirty.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to solid welds made in a noble gas shield.
Steel elements are laser-cut using modern equipment and then bent on CNC bending machines.
The front of the insert is equipped with heat-resistant glass that can withstand temperatures up to 800°C.
COMFORTABLE USE
Removable grate and The ash pan makes it easy to keep the insert clean.
The special perforated design of the handle protects against excessive heat, which increases the comfort of using the fireplace.
Reduced soot buildup thanks to the clean glass system (air guide).
Can be used in various installation conditions thanks to the adjustable legs and the movable exhaust outlet with 360° adjustment.
MODERN DESIGN
Decorative glass that can withstand temperatures up to 800°C, giving the fireplace a modern and elegant look and visually enlarging the front of the insert.
Elegant and comfortable handle.
Technical data
| Nominal power (kW) | 12 |
|---|---|
| Heating power range (kW) | 5.0 - 15.0 |
| Thermal Efficiency (%) | 82 |
| Max working pressure (bar) | 2 |
| Water capacity (l) | 35 |
| Flue gas temperature (oC) | 204 |
| Max billet length (cm) | 50 |
| Minimum required active field of outlet grilles (cm2) | 300 |
| Minimum required active area of inlet grilles (cm2) | 150 |
| Door opening | Left |
| Base material | Steel |
| Additional closing | No |
| diameter of the flue gas outlet | 200 |
| Energy class | A+ |
|---|---|
| Average power from water (kW) | 7 |
| Heat output for space heating (kW) | 5 |
| Seasonal Energy Efficiency (%) | 72 |
| CO emission (mg/m3) | 1173 |
| NOx emission (mg/m3) | 127 |
| OGC emission (mg/m3) | 48 |
| EEI | 108 |
| Pollen emission (mg/m3) | 24 |
| CO emission (at 13% O2) ≤ given in % | 0.093 |
| Certificates | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| EAN | 5901350021453 |
|---|---|
| Equipment | Air intake - built in , Ashpan, Combustion chamber lining, Decorative glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 67.6 |
|---|---|
| Height (cm) | 138.4 |
| Depth (cm) | 40.7 |
| Weight (kg) | 215 |
