Designations
Sku LUCY/PW/12/W/BLACK
Specification
Nominal power (kW) 12
Thermal Efficiency (%) 82
Certificates
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Weight (kg) 215
BLENDA/100/60/LUCY/12
REKOJESC/PERFOROWANA/NIKLOWANA
TERMOTEC/LUCY/12 V2/BLACK
KLAMKA/PERFOROWANA/MB/LUCY
S/4/G/607X477/NADIA/10
SZNUR/W/CZARNY/PODKLEJANY
LISTWA/GLASS/NADIA/10/LUCY/12
DEFLEKTOR/DOLNY/STAL/LUCY/12/MALOWANE
07BL-08-00-00/MALOWANE
Description
MAXIMUM ENERGY USE
The body and front of the insert are resistant to high temperatures thanks to the material used - high-quality steel.
A special water jacket assembly allows for the extraction of a large amount of heat from the exhaust gases and transferring it to the heating system, thus achieving high energy efficiency of the insert.
Built-in coil. The water jacket body is reinforced with pins. 1/2" inlet/outlet connector.
Efficient combustion and longer temperature retention thanks to the TERMOTEC combustion chamber lining - a heat-accumulating material that increases the temperature in the chamber.
A system of two deflectors that extend the exhaust gas path makes combustion more ecological.
Supply of air exclusively from the outside thanks to the built-in 125 mm air intake connector. Air intake is adjusted using a single regulator, eliminating errors resulting from improper use.
Triple combustion chamber ventilation system: primary air is supplied under the grate; secondary air is supplied through holes in the rear wall. Additionally, the insert uses a clean glass system (air curtain).
SAFETY AT THE HIGHEST LEVEL
Excellent tightness thanks to solid welds made in a noble gas shield.
Steel elements are laser-cut using modern equipment and then bent on CNC bending machines.
The front of the insert is equipped with heat-resistant glass that can withstand temperatures up to 660°C.
COMFORTABLE USE
The removable grate and ash pan make it easy to keep the insert clean.
The special perforated design of the handle protects against excessive heat, which contributes to the high comfort of using the fireplace.
Reduced soot buildup thanks to Clean glass system (air guide).
Can be used in various installation conditions thanks to adjustable legs and a 360° adjustable exhaust outlet.
MODERN DESIGN
Decorative glass that can withstand temperatures up to 660°C, giving the fireplace a modern and elegant look, visually enlarges the front of the insert.
Elegant and convenient handle.
Technical data
| Nominal power (kW) | 12 |
|---|---|
| Heating power range (kW) | 5.0 - 15.0 |
| Thermal Efficiency (%) | 82 |
| Max working pressure (bar) | 2 |
| Water capacity (l) | 35 |
| Flue gas temperature (oC) | 204 |
| Max billet length (cm) | 50 |
| Minimum required active field of outlet grilles (cm2) | 300 |
| Minimum required active area of inlet grilles (cm2) | 150 |
| Door opening | Left |
| Base material | Steel |
| Additional closing | No |
| diameter of the flue gas outlet | 200 |
| Energy class | A+ |
|---|---|
| Average power from water (kW) | 7 |
| Heat output for space heating (kW) | 5 |
| Seasonal Energy Efficiency (%) | 72 |
| CO emission (mg/m3) | 1173 |
| NOx emission (mg/m3) | 127 |
| OGC emission (mg/m3) | 48 |
| EEI | 108 |
| Pollen emission (mg/m3) | 24 |
| CO emission (at 13% O2) ≤ given in % | 0.093 |
| Certificates | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| EAN | 5902539503258 |
|---|---|
| Equipment | Combustion chamber lining |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 67.6 |
|---|---|
| Height (cm) | 138.4 |
| Depth (cm) | 40.7 |
| Weight (kg) | 215 |
