Designations
Sku AMELIA/PW/30/W
Specification
Nominal power (kW) 15
Thermal Efficiency (%) 85.5
Certificates
- Ecodesign
- BImSchV 2
Weight (kg) 201
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Built in smoke tubes and high flue, which increase the heat exchange surface.
Increased heat exchange surface due to built-in smoke tubes and high flue.
Regulation of chimney draft using built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Protection against overheating by the built-in coil pipe - connector input / output 1/2”.
CONVENIENT TO USE
Classic front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
The cold handle system which limits the risk of burns due to the possibility of removing it while burning.
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
Movable grate and ashpan enables to clean the insert.
Technical data
| Nominal power (kW) | 15 |
|---|---|
| Heating power range (kW) | 7 - 18 |
| Thermal Efficiency (%) | 85.5 |
| Max working pressure (bar) | 2 |
| Water capacity (l) | 60 |
| Flue gas temperature (oC) | 195 |
| Max billet length (cm) | 50 |
| Minimum required active field of outlet grilles (cm2) | 420 |
| Minimum required active area of inlet grilles (cm2) | 210 |
| Door opening | Left |
| Base material | Steel, Cast iron |
| Additional closing | No |
| diameter of the flue gas outlet | 180 |
| Energy class | A+ |
|---|---|
| Average power from water (kW) | 8 |
| Heat output for space heating (kW) | 7 |
| Seasonal Energy Efficiency (%) | 76 |
| CO emission (mg/m3) | 1018 |
| NOx emission (mg/m3) | 104 |
| OGC emission (mg/m3) | 85 |
| EEI | 114 |
| Pollen emission (mg/m3) | 12 |
| CO emission (at 13% O2) ≤ given in % | 0.081 |
| Certificates | Ecodesign, BImSchV 2 |
|---|
| EAN | 5901350028636 |
|---|---|
| Equipment | Ashpan |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 75 |
|---|---|
| Height (cm) | 95.9 |
| Depth (cm) | 51.1 |
| Weight (kg) | 201 |
Customer reviews
5.00 / 5
Have this product?
Rate Water heating fireplace KRATKI AMELIA 15 kW Ø 220 and help others to make a choice.
-
Pawel Kominek używam 8 lat ogrzewam 220 m 15m drzewa na sezon.grzejniki wymiary 140x6 sztuk 11 plus podłogowa.plus cwu 150l.polecam
Warranty and returns
Warranty
All products on www.kratki.com are brand new, free from physical and legal defects and have been legally launched on the Polish market. The manufacturer gives a 5-year warranty on the proper functioning of the fireplace stove from the moment of its purchase. Fireplace grates and seals are covered by a guarantee for a period of 1 year from the time of purchasing the fireplace stove. The guarantee does not cover: heat resistant ceramics. The use of the fireplace stove, method of installation to the chimney, and operating conditions must be in accordance with the instruction manual.
Returns
A Customer who is a Consumer and who has signed a Sales Agreement has the right to withdraw from it within 14 days without giving any reason. The withdrawal period begins on the day the Customer or a third party indicated by the Customer (other than the carrier) takes possession of the goods. The declaration of withdrawal may be submitted using the form provided by the Seller, available on the Store’s Website at the following address: withdrawal form.
