Steel fireplace KRATKI MBM right 10 kW Ø 200 black thermotec

MBM 10 kW steel fireplace insert with right hand window without muntin bar with Termotec lining.

Catalog number: ##MBM/P/BS/BLACK##.

Product information:

Complies with ECODESIGN requirements meets strict German norms BImSchV 2, setting maximum CO.



ENERGY CLASS A

made of high quality steel body and front resistant to very high temperatures.

efficient combustion and longer temperature retention thanks to Termotec black lining of the combustion chamber.

high flue and laterally placed smoke tubes increase the heat exchange surface between the insert and the environment.

the insert has a built-in air intake nozzle fi 125 mm.

designed for recuperation.

wide range of heating power from 4.5 to 12.5 kW.

high efficiency of up to 81%.

glazing with decorative glass type GLASS.

Technical data: .

Rated power (kW) 10.0.

Heating power range (kW) 4.5 - 12.5.

Thermal efficiency (%) 81.0.

Flue outlet diameter (mm) 200.

Complies with ECODESIGN criteria Yes.

Designed for recuperation Yes.

Weight (kg) 174.0.

CO emission (at 13% O 2 ) ≤ reported in % 0.10.

Flue gas temperature (℃) 235.0.

Max log length (cm) 50.

Pollen (dust) emission (mg/Nm3) 28.0.

BImSchV 2 compliant Yes.

Energy efficiency index EEI 106.71.

Minimum required active area of outlet grilles (cm2) ≥700.

Minimum required active area of inlet grilles (cm2) ≥500.

Type of side glazing.

Door opening to the right.

Construction material steel.

Width (cm) 77,50.

Height (cm) 126,10.

Depth (cm) 49,20.

Air intake Yes.

Lining of combustion chamber Yes.

Decorative glass Yes.

Fuel type: Recommended seasoned hardwoods with moisture content ≤20%.

Triple airing system for the combustion chamber.

Elegant and comfortable handle.

Precise air damper control.

Built-in air intake.

Decorative glass with air curtain (clean glass system) .

Termotec lining.



DECORATIVE GOLD AND SILVER HANDLES.

The fireplace has the possibility of replacing the handles. On our other auctions you can equip yourself with a gold or silver handle. The excellent quality of the material and special perforated construction ensure comfortable use.



DECORATIVE GLASS TYPE

The insert is equipped with a single, decorative GLASS pane that makes it look elegant and modern. This solution optically enlarges the front of the insert and emphasizes the vision of fire.



BUILT-IN REGULATION OF AIR INTAKE

The intake of outside air is regulated by a built-in damper located below the door. The whole mechanism works inside the fireplace very quietly and without any failures.



CLEAN GLASS SYSTEM

The air guide mounted on top of the front of the fireplace stove reduces soot build-up.



INNOVATIVE HANDLE

The special perforated structure of the handle protects it from excessive heat, which contributes to the high comfort of the fireplace.



MAXIMUM USE OF ENERGY

The body and front made of high-grade steel are resistant to very high temperatures.

Efficient combustion and longer temperature retention thanks to the lining of the combustion chamber with TERMOTEC, a heat-accumulating material that increases the temperature in the chamber.

High flue and laterally placed smoke tubes increase the heat exchange surface between the insert and the environment. Lowering the temperature of exhaust fumes contributes to higher efficiency of the device.

Stable and resistant to stress, the fireplace door is made of a closed profile. The door seal is located in a profiled channel that guarantees it fits properly and prevents it from falling out during use.

The combustion of fuel particles thanks to a deflector that extends the flue gas path.

Supply of air only from outside thanks to built-in air intake port Ø 125 mm. Adjustment of the air intake by means of a single regulator, which excludes errors in improper use.

Triple system of air supply to the combustion chamber: primary air - directed to the plate on which combustion takes place; secondary air is supplied through holes in the rear wall. Additionally, the clean glass system (air curtain) is used in the inset.



SAFETY AT THE HIGHEST LEVEL

Excellent tightness thanks to solid welds made in a noble gas shield.

Steel elements are laser cut with the use of modern equipment and then bent on CNC bending machines.

The front of the insert is equipped with heat resistant ceramics which can withstand temperatures up to 660°C.



ECOLOGICAL COMBUSTION

The device meets the requirements of Ecodesign and BImSchV 2 standards, setting the maximum CO emission.



COMFORTABLE USE

Insert without a grate - ash afterburning, which means that the fuel burns to a fine ash which remains in a minimal amount. Thus obtained heat energy from wood is used to the maximum extent.

The bottom plate of the insert is significantly lowered in relation to the door.

Soot formation is reduced thanks to the clean glass system (air guide vane).

The special perforated structure of the handle protects it from excessive heating, which contributes to the high comfort of using the fireplace.



MODERN DESIGN

Fireplace insert with two panes of glass set at right angles to each other (panes joined without a muntin bar).

Decorative glass that can withstand temperatures of up to 660°C gives the fireplace a modern and elegant look and optically enlarges the front of the insert.
