Designations
Sku ANTEK/DECO/150
Specification
Nominal power (kW) 10
Thermal Efficiency (%) 76.9
Certificates Ecodesign
Weight (kg) 85
NAKRETKA/M5/DIN6923/KL8/OCYNK
NAKRETKA/M6/DIN6923/KL8/OCYNK
NAKRETKA/M3/DIN934/KL8/OCYNK
SRUBA/M5X8/DIN914/45H/CZERNIONA
SRUBA/M6X12/ISO7380-2/10.9/CZERNIONA
SRUBA/M6X10/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X8/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X10/DIN6921/10.9/OCYNK
PODKLADKA/8,4/DIN9021/OCYNK
PODKLADKA/6,4/DIN9021/OCYNK
PODKLADKA/5,3/DIN9021/OCYNK
SRUBA/M5X10/DIN7984/8.8/CZERNIONA
SZNUR/W/CZARNY/PODKLEJANY
SPREZYNA/FI8/4MM/CZERNIONA
KLAMKA/PERFOROWANA/MB/LUCY
SRUBA/M8X20/DIN933/5.8/OCYNK
NAKRETKA/M5/DIN934/KL5/OCYNK
SRUBA/M5X8/DIN7984/8.8/OCYNK
ZATRZASK/ROLKOWY/METALOWY
BETON/BJORN/MOJAVE/GORA/NERO
Description
MAXIMUM USE OF ENERGY
Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm.
Increased heat exchange surface between the hot exhaust gases and the room due to the high flue.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Increased efficiency of the insert through manual control of chimney draft by using the built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
CONVENIENT TO USE
Ash drawer / ashtray, where the remains of burnt wood are gathered and grate for easy ash removal.
Reduced soot deposition through a system of pure glass (air curtain).
An elegant and comfortable handle.
MODERN DESIGN
Frame and door of the fireplace made of steel intended to work at elevated temperatures.
Technical data
| Version | Front facing |
|---|---|
| Nominal power (kW) | 10 |
| Heating power range (kW) | 4,5 - 13 |
| Thermal Efficiency (%) | 76.9 |
| Flue gas temperature (°C) | 300 |
| Max billet length (cm) | 33 |
| Minimum required active area of inlet grilles (cm2) | ≥500 |
| Minimum required active field of outlet grilles (cm2) | ≥700 |
| diameter of the flue gas outlet | 150 |
| Color | Black |
| Additional closing | No |
| Base material | Steel, Cast iron |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 102 |
| Seasonal Energy Efficiency (%) | 67 |
| Heat output for space heating (kW) | 10 |
| CO emission (at 13% O2) ≤ given in % | 0.135 |
| CO emission (mg/m3) | 1681 |
| Pollen emission (mg/m3) | 22 |
| NOx emission (mg/m3) | 116 |
| OGC emission (mg/m3) | 80 |
| Flue gas mass flow (g/s) | 9.1 |
| Certificates | Ecodesign |
|---|
| Equipment | Air intake - additional option, Ashpan, Decorative glass |
|---|---|
| FRONT | Steel front with painted glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Number of pieces in a package. | 2 |
| EAN | 5901350068588 |
| Width (cm) | 59.7 |
|---|---|
| Height (cm) | 62.2 |
| Depth (cm) | 35.5 |
| Weight (kg) | 85 |
