Vedfyrt stålovn ERIK GRILLES Ø 150 5,5 kW
- PRO rutenett
- Økodesign
- Restitusjon
- BImSchV 2
- 7* Flamme Verte
Beskrivelse
FREESTANDING STEEL STOVE ERIK
We are confident in the quality of our equipment.
By betting on our product you ensure peace of mind, trouble-free use and satisfaction with your purchase.
ADVANTAGES
- the decorative glass with aesthetically pleasing black decoration gives the stove an elegant appearance,
- a handle in the form of a railing provides a comfortable grip over its entire length,
- comfortable door opening thanks to a modern and durable mechanism,
- longer temperature maintenance due to lining of the combustion chamber with TERMOTEC accumulation material,
- intuitive air control,
- cast iron grate and steel ash pan,
- clean glass system to keep the glass clean,
- heat-resistant glazing with temperature resistance up to 600°C,
- deepened combustion chamber accommodates more wood and prevents ash from spilling into the room when refuelling,
- adjustable feet to compensate for uneven floor surfaces and level the stove,
- the threefold aeration system of the combustion chamber contributes to the high efficiency of the combustion process,
- deflector to extend the flue gas path for optimum use of energy,
- inspection door opening on the push-to-open principle,
- air intake via an external spigot (can be connected from the back or bottom) with a diameter of Ø 100,
- the stove is coated with a specially designed paint mixture with increased scratch resistance and uniform and smooth structure,
- possibilitý to connect the flue outlet either from the top or the back of the unit,
- easier stove installation thanks to the Ø200mm hole in the base,
- meets the criteria of the ECODESIGN, the strict German norm BlmschV II and Flamme Verte,
- designed for homes with recuperation.
Tekniske data
Rated output (kW) | 5.5 |
---|---|
Varmeeffektområde (kW) | 2,5-8,5 |
Heating efficiency (%) | 80.5 |
Eksostemperatur (oC) | 297 |
Max length of logs (cm) | 25 |
Color | Black |
Self Closure | False |
Door opening direction | Left |
Materials | stål |
Flue outlet diameter (mm) | 150 |
Air intake diameter (mm) | 100 |
N_energiklasse | A |
---|---|
EEI koeffisient | 106.7 |
Sesongmessig energieffektivitet (%) | 70.5 |
Termisk effekt for romoppvarming (kW) | 5.5 |
CO-utslipp (ved 13 % O2) ≤ gitt i % | 0.077 |
CO-utslipp (mg/m3) | 965 |
Pollenutslipp (mg/m3) | 21 |
NOx-utslipp (mg/m3) | 117 |
OGC-utslipp (mg/m3) | 103 |
Eksosmassestrøm (g/s) | 4 |
Meets requirements | PRO rutenett, Økodesign, Restitusjon, BImSchV 2, 7* Flamme Verte |
---|
Design features | Air intake - built in , Ashpan, Combustion chamber lining, Decorative glass |
---|---|
Front type | Steel front with bent painted glass |
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5903751232308 |
Width (cm) | 52.8 |
---|---|
Height (cm) | 103.9 |
Depth (cm) | 42.2 |
