Leírás
MAXIMUM USE OF ENERGY
Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm.
Increased heat exchange surface between the hot exhaust gases and the room due to the high flue.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Increased efficiency of the insert through manual control of chimney draft by using the built-in damper.
Manual control over the combustion process carried out by ash tray regulator.
SAFETY AT THE HIGHEST LEVEL
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
CONVENIENT TO USE
Ash drawer / ashtray, where the remains of burnt wood are gathered and grate for easy ash removal.
Large combustion chamber, which allows to load a large quantity of fuel without the need for frequent refills.
Reduced soot deposition through a system of pure glass (air curtain).
An elegant and comfortable handle.
The possibility of levelling the fireplace insert thanks to the adjustable legs.
MODERN DESIGN
Frame and door of the fireplace made of steel intended to work at elevated temperatures.
A fireplace insert with two panes compiled with each other at angles (without brackets).
Műszaki adatok
| Névleges teljesítmény (kW) | 21 |
|---|---|
| Termikus hatásfok (%) | 80 |
| Füstgáz hőmérséklete (°C) | 322 |
| Optimális rönkhossz (mm) | 300 |
| Max. tuskóhossz (cm) | 40 |
| A bemeneti rácsok minimálisan szükséges aktív területe (cm2) | ≥800 |
| A kimeneti rácsok minimálisan szükséges aktív területe (cm2) | ≥1000 |
| a füstgáz kimenetének átmérője | 200 |
| Energiaosztály | A |
|---|---|
| EEI | 106 |
| Szezonális energiahatékonyság (%) | 70 |
| Hőteljesítmény helyiségfűtéshez (kW) | 21 |
| CO-kibocsátás (13 % O2 mellett) ≤ %-ban | 0.134 |
| CO-kibocsátás (mg/m3) | 1675 |
| Pollenkibocsátás (mg/m3) | 16 |
| NOx-kibocsátás (mg/m3) | 102 |
| OGC-kibocsátás (mg/m3) | 82 |
| Füstgáz tömegáram (g/s) | 13.7 |
| Üzemanyag típusa | Fájdott lombhullató fa (páratartalom ≤20%) |
|---|---|
| darabok száma egy csomagban. | 1 |
| EAN | 5901350048498 |
| Szélesség (cm) | 81.45 |
|---|---|
| Magasság (cm) | 106.55 |
| Mélység (cm) | 49.1 |
| Waga | 211 |
