Steel fireplace KRATKI NBC 1000/400 15 kW Ø 200 Lift-up black thermotec
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Description
MAXIMUM ENERGY USE
The body and the front of the insert are resistant to high temperatures thanks to the high-quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to the lining of the combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Air supplied from outside only thanks to a built-in external air inlet of 125mm. Air adjustment with just one regulator, which prevents improper usage.
Triple air system of combustion chamber: primary air - directed to combustion plate; secondary air supplied by holes in the back wall. A system of air-clean glass (curtain air) has also been applied.
SAFETY AT ITS BEST
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC machines.
Front of the insert is equipped with triple heat-resistant ceramics that can withstand temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Movable grate and ashpan enable the cleaning of the insert.
The bottom plate of the insert is significantly reduced relative to the door.
Double door opening system - lift-up (Guillotine) and side opening. A lifted door makes the loading of wood easier, and the mechanism of the side door opening allows for the cleaning of the glass.
Reduced soot deposition through a system of pure glass (air curtain).
MODERN DESIGN
Three-side glazing of fireplace guarantees maximum vision of the fire.
Comfortable and quiet lift-up mechanism simplifies cleaning and service of the insert.
Decorative, heat-resistant glass can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look and visually enlarges the front of the insert.
Technical data
Rated output (kW) | 15 |
---|---|
Heating power range (kW) | 7 - 21 |
Heating efficiency (%) | 78 |
Exhaust gas temperature (℃) | 270 |
Max length of logs (cm) | 40 |
Flue outlet diameter (mm) | 200 |
Color | Black |
Materials | Steel |
Door opening direction | Up |
Energy class | A |
---|---|
Energy efficiency index (EEI) | 103 |
Seasonal Heating efficiency (%) | 68 |
Thermal power for space heating (kW) | 15 |
CO emissions (at 13% O 2 ) ≤ given in % | 0.1 |
Dust emission (mg/Nm3) | 24 |
Meets requirements | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
---|
Design features | Combustion chamber lining |
---|---|
Type of fuel | Seasoned deciduous wood (humidity ≤20%) |
EAN | 5903751192664 |
Width (cm) | 107.6 |
---|---|
Height (cm) | 147 |
Depth (cm) | 62.3 |
Weight (kg) | 330 |
