Designations
Sku ERIK/KONF
Specification
Nominal power (kW) 5.5
Thermal Efficiency (%) 80.5
Certificates
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
- 7* Flamme Verte
Description
FREESTANDING STEEL STOVE ERIK
We are confident in the quality of our equipment.
By betting on our product you ensure peace of mind, trouble-free use and satisfaction with your purchase.
ADVANTAGES
- the decorative glass with aesthetically pleasing black decoration gives the stove an elegant appearance,
- a handle in the form of a railing provides a comfortable grip over its entire length,
- comfortable door opening thanks to a modern and durable mechanism,
- longer temperature maintenance due to lining of the combustion chamber with TERMOTEC accumulation material,
- intuitive air control,
- cast iron grate and steel ash pan,
- clean glass system to keep the glass clean,
- heat-resistant glazing with temperature resistance up to 600°C,
- deepened combustion chamber accommodates more wood and prevents ash from spilling into the room when refuelling,
- adjustable feet to compensate for uneven floor surfaces and level the stove,
- the threefold aeration system of the combustion chamber contributes to the high efficiency of the combustion process,
- deflector to extend the flue gas path for optimum use of energy,
- inspection door opening on the push-to-open principle,
- air intake via an external spigot (can be connected from the back or bottom) with a diameter of Ø 100,
- the stove is coated with a specially designed paint mixture with increased scratch resistance and uniform and smooth structure,
- possibilitý to connect the flue outlet either from the top or the back of the unit,
- easier stove installation thanks to the Ø200mm hole in the base,
- meets the criteria of the ECODESIGN, the strict German norm BlmschV II and Flamme Verte,
- designed for homes with recuperation.
Technical data
| Nominal power (kW) | 5.5 |
|---|---|
| Heating power range (kW) | 2,5-8,5 |
| Thermal Efficiency (%) | 80.5 |
| Flue gas temperature (oC) | 297 |
| Optimal log length (mm) | 250 |
| Max billet length (cm) | 35 |
| Base material | Steel |
| Color | Black |
| Additional closing | No |
| Door opening | Left |
| diameter of the flue gas outlet | 150 |
| Air intake diameter (mm) | 100 |
| Energy class | A |
|---|---|
| EEI | 106.7 |
| Seasonal Energy Efficiency (%) | 70.5 |
| Heat output for space heating (kW) | 5.5 |
| CO emission (at 13% O2) ≤ given in % | 0.077 |
| CO emission (mg/m3) | 965 |
| Pollen emission (mg/m3) | 21 |
| NOx emission (mg/m3) | 117 |
| OGC emission (mg/m3) | 103 |
| Flue gas mass flow (g/s) | 4 |
| Certificates | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2, 7* Flamme Verte |
|---|
| Number of pieces in a package. | 2 |
|---|---|
| EAN | 5903751232308 |
| Equipment | Air intake - built in , Ashpan, Combustion chamber lining, Decorative glass |
| FRONT | Steel front with bent painted glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 52.8 |
|---|---|
| Height (cm) | 103.9 |
| Depth (cm) | 42.2 |
Customer reviews
-
C *******D *************** Names are generated randomly due to personal data protection. gggg
- M ******H *********** Names are generated randomly due to personal data protection.
Doskonały kontakt pełna profeska.
- N *****M ****** Names are generated randomly due to personal data protection.
obsługa na wysokim poziomie Polecam
- H *********P *************** Names are generated randomly due to personal data protection.
Obsługa perfekcyjna
- A **********O ************* Names are generated randomly due to personal data protection.
Nie trzeba ulepszeń
Warranty and returns
Warranty
All the products available at www.kratki.com are brand new, free from any physical or legal defects. The Producer grants a 5-year warranty from the moment of purchase of a stove for its reliable operation. The ceramic liner is covered with a 2-year warranty from the moment of the purchase of the stove. Grate and sealing for the stove are covered with a 1-year warranty from the moment of the purchase of the stove. The warranty shall not cover heat-resistant ceramics. The application of the stove, the method of joining with the chimney as well as the terms and conditions of use must correspond with the manual.
Returns
A Customer who is a Consumer and who has signed a Sales Agreement has the right to withdraw from it within 14 days without giving any reason. The withdrawal period begins on the day the Customer or a third party indicated by the Customer (other than the carrier) takes possession of the goods. The declaration of withdrawal may be submitted using the form provided by the Seller, available on the Store’s Website at the following address: withdrawal form.
