Designations
Sku ERIK/KONF
Specification
Nominal power (kW) 5.5
Thermal Efficiency (%) 80.5
Certificates
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
- 7* Flamme Verte
Description
FREESTANDING STEEL STOVE ERIK
We are confident in the quality of our equipment.
By betting on our product you ensure peace of mind, trouble-free use and satisfaction with your purchase.
ADVANTAGES
- the decorative glass with aesthetically pleasing black decoration gives the stove an elegant appearance,
- a handle in the form of a railing provides a comfortable grip over its entire length,
- comfortable door opening thanks to a modern and durable mechanism,
- longer temperature maintenance due to lining of the combustion chamber with TERMOTEC accumulation material,
- intuitive air control,
- cast iron grate and steel ash pan,
- clean glass system to keep the glass clean,
- heat-resistant glazing with temperature resistance up to 600°C,
- deepened combustion chamber accommodates more wood and prevents ash from spilling into the room when refuelling,
- adjustable feet to compensate for uneven floor surfaces and level the stove,
- the threefold aeration system of the combustion chamber contributes to the high efficiency of the combustion process,
- deflector to extend the flue gas path for optimum use of energy,
- inspection door opening on the push-to-open principle,
- air intake via an external spigot (can be connected from the back or bottom) with a diameter of Ø 100,
- the stove is coated with a specially designed paint mixture with increased scratch resistance and uniform and smooth structure,
- possibilitý to connect the flue outlet either from the top or the back of the unit,
- easier stove installation thanks to the Ø200mm hole in the base,
- meets the criteria of the ECODESIGN, the strict German norm BlmschV II and Flamme Verte,
- designed for homes with recuperation.
Technical data
| Nominal power (kW) | 5.5 |
|---|---|
| Heating power range (kW) | 2,5-8,5 |
| Thermal Efficiency (%) | 80.5 |
| Flue gas temperature (oC) | 297 |
| Optimal log length (mm) | 250 |
| Max billet length (cm) | 35 |
| Base material | Steel |
| Color | Black |
| Additional closing | No |
| Door opening | Left |
| diameter of the flue gas outlet | 150 |
| Air intake diameter (mm) | 100 |
| Energy class | A |
|---|---|
| EEI | 106.7 |
| Seasonal Energy Efficiency (%) | 70.5 |
| Heat output for space heating (kW) | 5.5 |
| CO emission (at 13% O2) ≤ given in % | 0.077 |
| CO emission (mg/m3) | 965 |
| Pollen emission (mg/m3) | 21 |
| NOx emission (mg/m3) | 117 |
| OGC emission (mg/m3) | 103 |
| Flue gas mass flow (g/s) | 4 |
| Certificates | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2, 7* Flamme Verte |
|---|
| Number of pieces in a package. | 2 |
|---|---|
| EAN | 5903751232308 |
| Equipment | Air intake - built in , Ashpan, Combustion chamber lining, Decorative glass |
| FRONT | Steel front with bent painted glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 52.8 |
|---|---|
| Height (cm) | 103.9 |
| Depth (cm) | 42.2 |
