Designations
Sku WK/440/KAFEL/K
Specification
Nominal power (kW) 5.5
Thermal Efficiency (%) 80
Certificates
- Ecodesign
- BImSchV 2
Weight (kg) 130
NAKRETKA/M6/DIN934/KL8/OCYNK
SRUBA/M6X16/DIN7991/10.9/CZERNIONA
SRUBA/M6X12/DIN7991/10.9/CZERNIONA
SRUBA/M5X8/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X8/ISO7380-1/10.9/CZERNIONA
SRUBA/M5X10/ISO7380-2/10.9/CZERNIONA
SZNUR/W/CZARNY/PODKLEJANY
BETON/BJORN/MOJAVE/GORA/NERO
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Manual control over the combustion process carried out by ash tray regulator.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
CONVENIENT TO USE
Reduced soot deposition through a system of pure glass (air curtain).
STYLE & DESIGN
Design reffering to retro style - glossy tile panels. The casing from tile panels effects for prolonged heat rejection, which provides additional source of heating after extinction.
Stoves with tile panels produced by Kratki company are classified as solid-fuel boiler with manual loading of fuel and lockable door. They are used as additional source of heating in interiors where they are installed.
Technical data
| Nominal power (kW) | 5.5 |
|---|---|
| Heating power range (kW) | 3.0 - 9.3 |
| Thermal Efficiency (%) | 80 |
| Flue gas temperature (oC) | 279 |
| Max billet length (cm) | 30 |
| Base material | Steel, Tile |
| Additional closing | No |
| Door opening | Left |
| diameter of the flue gas outlet | 130 |
| Energy class | A |
|---|---|
| EEI | 106 |
| Seasonal Energy Efficiency (%) | 70 |
| Heat output for space heating (kW) | 5.5 |
| CO emission (at 13% O2) ≤ given in % | 0.099 |
| CO emission (mg/m3) | 1237 |
| Pollen emission (mg/m3) | 31 |
| NOx emission (mg/m3) | 110 |
| OGC emission (mg/m3) | 85 |
| Flue gas mass flow (g/s) | 4.7 |
| Certificates | Ecodesign, BImSchV 2 |
|---|
| Number of pieces in a package. | 2 |
|---|---|
| EAN | 5901350059654 |
| Equipment | Ashpan, Combustion chamber lining |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Width (cm) | 75 |
|---|---|
| Height (cm) | 74.8 |
| Depth (cm) | 37.7 |
| Weight (kg) | 130 |
Customer reviews
5.00 / 5
Have this product?
Rate Tiled wood burning steel stove KRATKI WK440 Ø 130 5,5 kW cream tile and help others to make a choice.
- Piotr
Polecam... ale nie za tą cene ja płaciłem 2500zł piec spełnia swoją rolę miałem też wymianę gwarancyjną ponieważ pęka ceramika nad drzwiami paleniska oraz spoiny się kruszą
Warranty and returns
Warranty
All the products available at www.kratki.com are brand new, free from any physical or legal defects. The Producer grants a 5-year warranty from the moment of purchase of an insert for its reliable operation. The ceramic liner of the combustion chamber is covered with a 2-year warranty from the moment of the purchase of the insert. Grate and sealing for the fireplace are covered with a 1-year warranty from the moment of the purchase of the insert. The warranty shall not cover heat-resistant ceramics. The application of the fireplace insert, the method of joining with the chimney as well as the terms and conditions of use must correspond with the manual.
Returns
A Customer being a Consumer, who has concluded the Sales Contract may rescind thereof within a period of 14 days without giving any reasons. The time limits run for the rescission of the Sales Contract shall commence at the time of acquiring the Goods by the Customer or a third party of their choice, other, however, than a carrier. The representations may be submitted in a form whose template has been published by the Seller at the Online Shop Website.
