Designations
Sku NADIA/10/KONF
Specification
Nominal power (kW) 10
Thermal Efficiency (%) 80
Certificates
- KRATKI PRO
- Ecodesign
- Designed for recuperation
- BImSchV 2
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall.
The cleanliness of combustion chamber thanks to hexagonal hearth.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Front of insert is equipped with a heat-resistant ceramics that can withstand temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum.
Reduced soot deposition through a system of pure glass (air curtain).
It can be used in a various mounting conditions thanks to adjustable legs and movable fumes outlet with 360 regulation.
Possibillity to change the direction of door opening from a standard left-hand opening to the right-hand opening.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Elegant and comfortable sliding handle.
Technical data
| Version | Front facing |
|---|---|
| Nominal power (kW) | 10 |
| Heating power range (kW) | 5.0 - 12.5 |
| Thermal Efficiency (%) | 80 |
| Flue gas temperature (oC) | 255 |
| Max billet length (cm) | 35 |
| Minimum required active area of inlet grilles (cm2) | ≥700 |
| Minimum required active field of outlet grilles (cm2) | ≥900 |
| diameter of the flue gas outlet | 200 |
| Color | Black |
| Additional closing | No |
| Base material | Steel |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 105 |
| Seasonal Energy Efficiency (%) | 70 |
| Heat output for space heating (kW) | 10 |
| CO emission (at 13% O2) ≤ given in % | 0.08 |
| CO emission (mg/m3) | 1003 |
| Pollen emission (mg/m3) | 32 |
| NOx emission (mg/m3) | 112 |
| OGC emission (mg/m3) | 38 |
| Flue gas mass flow (g/s) | 9.5 |
| Certificates | KRATKI PRO, Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Equipment | Air intake - built in , Combustion chamber lining, Decorative glass |
|---|---|
| FRONT | Steel front with painted glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Number of pieces in a package. | 2 |
| EAN | 5901350061190 |
| Width (cm) | 68.4 |
|---|---|
| Height (cm) | 121.1 |
| Depth (cm) | 41.8 |
