Steel fireplace KRATKI LUCY TUNNEL 12 kW Ø 200

MAXIMUM ENERGY USE

More efficient combustion and longer temperature retention thanks to the TERMOTEC combustion chamber lining, a heat-accumulating material that raises the temperature in the combustion chamber.

Fuel particles are burned thanks to two deflectors that extend the exhaust gas path. This process also increases combustion efficiency and guarantees better energy utilization, thus minimizing harmful emissions into the atmosphere.

Air is supplied to the insert exclusively from the outside, thanks to the built-in 125 mm air intake. Air is regulated using a single damper located below the door, eliminating errors due to improper use. The entire mechanism operates very quietly and reliably.

The insert uses a double combustion chamber ventilation system. Primary air, which facilitates wood ignition, is supplied under the grate.

Additionally, the insert uses a clean glass system (air curtain), which means air is supplied directly to the glass through a system of channels located on the sides of the fireplace. This delivers oxygen to the upper part of the combustion chamber, where the gases produced during wood combustion are burned, further reducing harmful CO emissions into the atmosphere. This air supply system allows for very precise control of the combustion process. The device meets the requirements of Ecodesign and the BImSchV 2 standard, which sets maximum CO emissions. The front of the insert is equipped with heat-resistant ceramics that can withstand temperatures up to 660°C. The glass we offer is certified for quality and safety.

The special perforated design of the handle protects against excessive heat, which contributes to the high comfort of using the fireplace.

The body and front of the insert are resistant to high temperatures thanks to the use of high-quality steel.

Excellent tightness thanks to solid welds made with a noble gas shield. Steel elements are laser-cut using modern equipment and then bent on CNC bending machines.

COMFORTABLE TO USE

The fireplace features a specially profiled bottom plate made of TERMOTEC material, which allows for a deeper combustion chamber and greater wood capacity.

The removable grate and ash pan make it easy to keep the insert clean.

Limited soot buildup is achieved thanks to the clean glass system. An air curtain separates the glass from the firebox. This prevents it from becoming dirty and releases more heat into the room.

Adjustable legs allow for leveling and leveling of the insert.

This model is equipped with a movable exhaust outlet, eliminating the need to purchase additional elbows during installation. You can easily adjust the angle at which the insert connects to the chimney. The insert has two doors, one front and one back (instead of a back wall), allowing heat to radiate in two directions. This type of fireplace is often chosen for installation between adjacent rooms, such as a living room, dining room, or bedroom. The insert has a single, decorative glass pane, giving it an elegant and modern look. This solution visually enlarges the front of the insert and highlights the fire. The insert door has a convenient handle. The insert has a convenient handle.
