Designations
Sku BLANKA/670/570/KONF
Specification
Nominal power (kW) 11
Thermal Efficiency (%) 78
Certificates
- Ecodesign
- BImSchV 2
BETON/BJORN/MOJAVE/GORA/NERO
07BL6757-08-00-00/MALOWANE
SRUBA/M6X12/DIN7991/10.9/CZERNIONA
SRUBA/M6X10/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X8/ISO7380-2/10.9/CZERNIONA
SZNUR/W/CZARNY/PODKLEJANY
SRUBA/M5X8/ISO7380-1/10.9/CZERNIONA
Description
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Built-in fi 125 external air intake which provides air supply from the outside directly into the hearth which results in better combustion and better comfort of usage.
Reducing emissions of harmful CO to the atmosphere by regulating of secondary air supply.
Maximum usage of heat thanks to densely spaced radiators.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
CONVENIENT TO USE
An elegant and comfortable handle.
It can be used in a various mounting conditions thanks to adjustable legs and movable fumes outlet with 360 regulation.
Technical data
| Version | Front facing |
|---|---|
| Nominal power (kW) | 11 |
| Heating power range (kW) | 7.1 - 14.5 |
| Thermal Efficiency (%) | 78 |
| Flue gas temperature (oC) | 277 |
| Optimal log length (mm) | 300 |
| Max billet length (cm) | 50 |
| Minimum required active area of inlet grilles (cm2) | ≥700 |
| Minimum required active field of outlet grilles (cm2) | ≥900 |
| diameter of the flue gas outlet | 180 |
| Air intake diameter (mm) | 125 |
| Color | Black |
| Additional closing | No |
| Base material | Steel |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 102 |
| Seasonal Energy Efficiency (%) | 68 |
| Heat output for space heating (kW) | 11 |
| CO emission (at 13% O2) ≤ given in % | 0.086 |
| CO emission (mg/m3) | 1071 |
| Pollen emission (mg/m3) | 40 |
| NOx emission (mg/m3) | 133 |
| OGC emission (mg/m3) | 47 |
| Flue gas mass flow (g/s) | 10.1 |
| Certificates | Ecodesign, BImSchV 2 |
|---|
| Equipment | Air intake - built in , Ashpan, Combustion chamber lining |
|---|---|
| FRONT | Steel front with ceramic glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Number of pieces in a package. | 2 |
| EAN | 5901350050910 |
| Width (cm) | 76.5 |
|---|---|
| Height (cm) | 98.9 |
| Depth (cm) | 41 |
