Designations
Sku KASETA/TUNEL/80/BLACK
Specification
Nominal power (kW) 12
Thermal Efficiency (%) 75
Certificates
- Ecodesign
- BImSchV 2
Weight (kg) 144
SZNUR/W/CZARNY/PODKLEJANY
07BL-08-00-00/MALOWANE
Description
ARKE 80 Tunnel Cassette - the double-sided magic of real fire
ARKE 80 Tunnel is a modern and exceptionally elegant built-in fireplace cassette. Its minimalist form, refined details, and tunnel design make the fireplace the heart of the home – suitable for both classic and contemporary interiors.
The double-sided design of the ARKE Tunnel cassette opens up completely new spatial possibilities. Glazing on both sides of the firebox allows natural light and the warmth of the flames to be transferred to two adjacent zones simultaneously. It's an ideal solution for installation in a partition wall between the living room and dining room, a lounge area and a bedroom, or in open-plan loft spaces. The double-sided view of the fire not only visually enlarges and illuminates the interior, but also becomes a natural link between the spaces – creating architectural coherence and a unique, cozy atmosphere throughout the house.
Why choose the ARKE 80 TUNEL?
■ Double-sided view of the fire – glazing on both sides allows you to admire the flames from two rooms simultaneously, creating a unique atmosphere and effectively connecting spaces,
■ Decorative effect – the natural glow of the fire penetrates the cassette, adding lightness to the entire structure,
■ Prolonged temperature retention – the interior of the combustion chamber is lined with TERMOTEC heat-storing material, which increases the temperature in the combustion chamber and releases heat after the fire has gone out.
■ Intuitive air supply regulation – control over the combustion process with a single regulator.
■ Ergonomic, perforated handle – a specially designed handle prevents excessive heating, ensuring safe and comfortable operation,
■ Cast iron grate and steel ash pan – quick, trouble-free cleaning and everyday convenience,
■ Triple air circulation – contributes to the high efficiency of the combustion process.
■ Air intake via an external connector with a diameter of 125 mm.
■ Clean glass system – precise air supply reduces soot build-up, leaving the glass clear for a long time.
■ Heat-resistant glass with an elegant black decor – the temperature resistance of the glass up to 660°C ensures safe operation, and the black decor around the edges of the glass gives the cassette a modern, minimalist look and optically enlarges the field of view of the fire.
Technical data
| Nominal power (kW) | 12 |
|---|---|
| Heating power range (kW) | 9.0 - 15.0 |
| Thermal Efficiency (%) | 75 |
| Flue gas temperature (°C) | 319 |
| Optimal log length (mm) | 330 |
| Max billet length (cm) | 50 |
| diameter of the flue gas outlet | 200 |
| Air intake diameter (mm) | 125 |
| Base material | Steel |
| Energy class | A |
|---|---|
| EEI | 98.8 |
| Seasonal Energy Efficiency (%) | 65 |
| CO emission (at 13% O2) ≤ given in % | 0.124 |
| CO emission (mg/m3) | 1208 |
| Pollen emission (mg/m3) | 34 |
| NOx emission (mg/m3) | 102 |
| OGC emission (mg/m3) | 54 |
| Flue gas mass flow (g/s) | 11.6 |
| Certificates | Ecodesign, BImSchV 2 |
|---|
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
|---|---|
| EAN | 5903751478973 |
| Width (cm) | 85 |
|---|---|
| Height (cm) | 61.4 |
| Depth (cm) | 45.2 |
| Weight (kg) | 144 |
