Designations
Sku FRANEK/14/DECO
Specification
Nominal power (kW) 14
Thermal Efficiency (%) 81
Certificates
- Ecodesign
- Designed for recuperation
- BImSchV 2
Weight (kg) 249
KLAMKA/PERFOROWANA/MB/LUCY
BETON/BJORN/MOJAVE/GORA/NERO
FR-10005/L/MALOWANE
FR2-10015/L/OBR/W/MALOWANE
FR2-10015/P/OBR/W/MALOWANE
SRUBA/M8X35/DIN7991/10.9/CZERNIONA
SRUBA/M5X8/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X8/ISO7380-1/10.9/CZERNIONA
SRUBA/M5X6/ISO7380-2/10.9/CZERNIONA
SRUBA/M5X10/ISO7380-2/10.9/CZERNIONA
S/4/G/739X460/FRANEK/14/PF/SS
Description
MAXIMUM USE OF ENERGY
Maximum use of heat due to densely spaced radiators and the wall of the insert made of high quality cast iron with a thickness of 8 mm.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Triple system of combustion chamber`s air venting: primary air - secondary air supplied under the grate through holes in a back wall. Additionally clean glass system designed (air curtain).
Manual control over the combustion process carried out by ash tray regulator.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm.
SAFETY AT THE HIGHEST LEVEL
Decorative fence helps to maintain the tidiness and protects against falling out of wood.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Large combustion chamber, which allows to load a large quantity of fuel without the need for frequent refills.
Reduced soot deposition through a system of pure glass (air curtain).
Movable, two-piece cast iron fumes outlet with the 360 regulation which can be directed upward or backward.
Movable two-piece cast iron grate.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Technical data
| Version | Front facing |
|---|---|
| Nominal power (kW) | 14 |
| Thermal Efficiency (%) | 81 |
| Flue gas temperature (oC) | 249 |
| Max billet length (cm) | 60 |
| Minimum required active area of inlet grilles (cm2) | ≥800 |
| Minimum required active field of outlet grilles (cm2) | ≥1000 |
| diameter of the flue gas outlet | 200 |
| Color | Black |
| Additional closing | No |
| Base material | Cast iron |
| Door opening | Left |
| Energy class | A |
|---|---|
| EEI | 106 |
| Seasonal Energy Efficiency (%) | 71 |
| Heat output for space heating (kW) | 14 |
| CO emission (at 13% O2) ≤ given in % | 0.092 |
| CO emission (mg/m3) | 1152 |
| Pollen emission (mg/m3) | 19 |
| NOx emission (mg/m3) | 99 |
| OGC emission (mg/m3) | 40 |
| Flue gas mass flow (g/s) | 12.4 |
| Certificates | Ecodesign, Designed for recuperation, BImSchV 2 |
|---|
| Equipment | Air intake - built in , Ashpan, Decorative glass |
|---|---|
| FRONT | Steel front with painted glass |
| Fuel type | Seasoned deciduous wood (humidity ≤20%) |
| Number of pieces in a package. | 1 |
| EAN | 5903751141655 |
| Width (cm) | 80 |
|---|---|
| Height (cm) | 96.9 |
| Depth (cm) | 47.6 |
| Weight (kg) | 249 |
