Cast iron fireplace insert KRATKI NEL Ø 180 8 kW

    Designations
    Sku NEL/DECO
    Specification
    Nominal power (kW) 8
    Thermal Efficiency (%) 81.1
    Certificates
    • Ecodesign
    • BImSchV 2
    Weight (kg) 109.08

    Description

    NEL/DECO - the power of cast iron in a modern form

    NEL/DECO is a modern, cast iron fireplace insert that combines the legendary durability of cast iron with elegant design. Thanks to the use of a steel front with heat-resistant glass with a decorative pattern (DECO), the insert gains a visual lightness and modern character, perfectly matching current interior design trends. It's the perfect solution for those who don't want to compromise between solid construction and interior aesthetics.

    The insert's front, equipped with decorative glass, visually enlarges the firebox, making the vision of the fire the focal point of the living room. This fireplace will work perfectly in both cozy, traditional interiors and austere, modern spaces.

    Ecology for the Environment

    The NEL insert has been designed to utilize every calorie of heat. Radiators on the device body and walls made of high-quality 8 mm thick cast iron guarantee maximum heat recovery and transfer.

    The device meets Ecodesign standards and other stringent environmental requirements of regional regulations regarding emission standards for fireplaces and other solid fuel heating appliances, including Ecodesign and BImSchV 2. It has also been tested to the rigorous EN 16510 standard.

    The fuel particle combustion system and the deflector that extends the exhaust gas path make the combustion process exceptionally efficient and economical.

    This guarantees clean combustion and high energy efficiency while protecting the environment. It is a reliable heat source that combines safety, durability, and environmental care.

    Quality and comfort of use for years to come

    The NEL insert is constructed of solid cast iron and high-quality steel and heat-resistant ceramics used in the front, ensuring safety and reliability for many years of use. Attention to detail is evident in every element – from the precise craftsmanship to the functional additions. A decorative fence inside the firebox protects wood from falling out, and the drawer-style ash pan makes it easy to empty any remaining ash.

    Why choose the NEL/DECO insert:

    • Deco glass (DECO) - decorative glass with a black print adds elegance and visually enlarges the front of the insert.
    • Air inlet (optional) - the fireplace draws air from the room; the device can be equipped with an optional inlet connector for cast iron inserts.
    • Built-in damper - allows for chimney draft regulation, which results in a more efficient combustion process.
    • High-quality cast iron - 8 mm thick walls and densely spaced radiators ensure excellent heat accumulation and release,
    • Steel front with heat-resistant glass - temperature resistance up to 660°C guarantees safe use.
    • Clean glass system - the air guide (air curtain) reduces soot build-up,
    • Perforated handle - the modern handle design means it heats up much slower and cools down faster than a traditional handle.
    • Triple air supply system - primary, secondary air, and an air curtain to optimize the combustion process.
    • Decorative fence - makes it easier to keep the stove clean and protects against wood falling out.
    • Universal dimensions - front width of approx. 70 cm (694 mm) allows for installation in many types of buildings,
    • 5-year warranty - assurance of safety and quality.

    Technical data

    General data
    Nominal power (kW)8
    Thermal Efficiency (%)81.1
    Flue gas temperature (oC)238
    Optimal log length (mm)300
    Max billet length (cm)35
    diameter of the flue gas outlet180
    Base materialCast iron
    Energetic efficiency
    Energy classA+
    EEI108
    Seasonal Energy Efficiency (%)71
    Heat output for space heating (kW)8
    CO emission (at 13% O2) ≤ given in %0.096
    CO emission (mg/m3)1210
    Pollen emission (mg/m3)27
    NOx emission (mg/m3)126
    OGC emission (mg/m3)99
    Flue gas mass flow (g/s)8.3
    Certifications / Compliance
    CertificatesEcodesign, BImSchV 2
    Additional information
    Fuel typeSeasoned deciduous wood (humidity ≤20%)
    EAN5903751403203
    Physical parameters
    Width (cm)69.4
    Height (cm)61.1
    Depth (cm)43.2
    Weight (kg)109.08
