Sku NADIA/13/BLACK
Specifikacija
Nazivna snaga (kW) 13
Učinkovitost grijanja (%) 81
Zadovoljava zahtjeve
- KRATKI PRO
- Ekološki dizajn
- Dizajniran za oporavak
- BImSchV 2
Waga 178
143,75 €Cijena uključuje PDVBLENDA35/NADIA/13
155,40 €Cijena uključuje PDVBLENDA70/NADIA/13
244,76 €Cijena uključuje PDVBLENDA/NADIA/13
158,00 €Cijena uključuje PDVDOMYKANIE/L/2 Availability: 14 Days
18,58 €Cijena uključuje PDVKLEJ/K-84
61,38 €Cijena uključuje PDVKLEJ/MAX
1,25 €Cijena uključuje PDVKOLEK
376,87 €Cijena uključuje PDVMSK/GLASS/P125
1,76 €Cijena uključuje PDVOPASKA/SLIMAKOWA
1.330,30 €Cijena uključuje PDVPAK2200
1.688,87 €Cijena uključuje PDVPAKADAMDW200
12,46 €Cijena uključuje PDVREWIZJA/15/B
23,99 €Cijena uključuje PDVZAPALARKA/KRATKI.COM Availability: 14 Days
549,80 €Cijena uključuje PDVTERMOTEC/NADIA/13/BLACK
1.810,00 €Cijena uključuje PDVS/4/G/757X607/NADIA/13 Availability: 14 Days
103,00 €Cijena uključuje PDVLISTWA/GLASS/NADIA/12/13 Availability: 14 Days
5,00 €Cijena uključuje PDVSZNUR/W/P/K/10X1 Availability: 14 Days
13,86 €Cijena uključuje PDVSZNUR/W/CZARNY/PODKLEJANY Availability: 14 Days
Opis
MAXIMUM USE OF ENERGY
The body and the front of the insert are resistant to high temperatures thanks to the high quality steel used in production.
Efficient burning process & maintaining of temperature to keep the warmth for longer thanks to lining of combustion chamber with TERMOTEC - heat accumulating material which raises the temperature in the combustion chamber.
Combustion of fuel particles thanks to deflector, which extends the exhaust gas path.
Air supplied from outside only thanks to biult-in an external air inlet fi 125mm. Air adjustment with just one regulator which prevents from improper usage.
Triple air system of combustion chamber: primary air- directed to combustion plate; secondary air supplied by the holes located in the back wall. Additionally, the system of air clean glass has been applied (curtain air).
The cleanliness of combustion chamber thanks to hexagonal hearth.
SAFETY AT THE HIGHEST LEVEL
Perfect tightness thanks to the solid welds made in a noble gas shielding.
All steel elements are laser cut and bent on CNC bending machines.
Insert`s front equipped with a heat resistant ceramics that withstands temperatures up to 660°C.
ECOLOGICAL COMBUSTION
The unit meets the requirements of Ecodesign standards and the restrictions of the BImSchV 2 standard, which determines the maximum CO emission.
CONVENIENT TO USE
Grateless fireplace insert - full combustion on the dust what means that firewood burns into fine ash at minimum amount. Obtained thermal energy from firewood is exploited to the maximum.
Reduced soot deposition through a system of pure glass (air curtain).
It can be used in a various mounting conditions thanks to adjustable legs and movable fumes outlet with 360 regulation.
Possibillity to change the direction of door opening from a standard left-hand opening to the right-hand opening.
MODERN DESIGN
Decorative, heat-resistant glass that can withstand temperatures up to 660°C. It gives a fireplace a modern and elegant look, visually enlarges the front of the insert.
Elegant and comfortable sliding handle.
Tehnički podaci
| Verzija | Prednja strana |
|---|---|
| Nazivna snaga (kW) | 13 |
| Raspon snage grijanja (kW) | 6.0 - 16.5 |
| Učinkovitost grijanja (%) | 81 |
| Temperatura ispušnog plina (℃) | 240 |
| Maksimalna duljina trupaca (cm) | 40 |
| Min. aktivno polje ulazne rešetke (cm2) | ≥700 |
| Min. aktivno polje izlazne mreže (cm2) | ≥900 |
| Promjer dimovodnog otvora (mm) | 200 |
| Boja | Crno |
| Samozatvaranje | False |
| Materijali | Željezo |
| Sustav otvaranja vrata | Lijevo |
| Energetski razred | A |
|---|---|
| Indeks energetske učinkovitosti (EEI) | 106.71 |
| Toplinska snaga za grijanje prostora (kW) | 13 |
| Emisije CO (pri 13% O 2 ) ≤ dano u % | 0.09 |
| Emisija prašine (mg/Nm3) | 37 |
| Zadovoljava zahtjeve | KRATKI PRO, Ekološki dizajn, Dizajniran za oporavak, BImSchV 2 |
|---|
| Značajke dizajna | Dekorativno staklo, Dovod zraka - ugrađen, Obloga komore za izgaranje |
|---|---|
| Prednja vrsta | Čelična prednja strana s obojenim staklom |
| Vrsta goriva | Začinjeno listopadno drvo (vlažnost ≤20%) |
| EAN | 5901350034132 |
| širina (cm) | 83.4 |
|---|---|
| Visina (cm) | 133.1 |
| Dubina (cm) | 41.8 |
| Waga | 178 |
