Steel fireplace KRATKI MAGMA 13 kW for custom masonry enclosures

Looking for a fireplace that will not only delight with the sight of the flames but will also become a real pillar of your home's heating system? Discover the MAGMA stove-mounted version – a robust, grateless built-in fireplace designed for efficient heating and a perfect fit with custom built-ins.

Maximum efficiency and solid construction

The fireplace's durability is based on a solid 4 mm thick steel body, designed for trouble-free operation and resistance to thermal loads. An optimized triple air supply system ensures a stable combustion process. It includes primary air supplied to the firebox floor for easier lighting, secondary air to burn the gases in the side sections and increase fuel efficiency, and an air curtain that protects the glass from soot and dirt buildup.

The entire process is controlled in an extremely intuitive manner using a single regulator, which allows for quick and precise adjustment of the damper position and the degree of its opening to the required flow rate. For maximum safety, the design prevents complete shutoff of primary air, ensuring a constant, minimal flow of air to the combustion zone.

View of the fire and ease of use

The double-glazed door provides exceptional visual and thermal comfort. The use of secondary glazing reduces heat radiation through the front and lowers the temperature of the outer glass, while retaining more energy inside the combustion chamber for a more efficient process.

The fireplace's design focuses on practical solutions that significantly simplify daily operation. The chamber lining with TERMOTEC material supports even temperature distribution and stable operation, while the double glazing retains more heat inside the combustion chamber, reducing heat loss through the glazing. The lack of a grate means the fuel burns more efficiently and evenly directly at the bottom of the firebox, and the whole is complemented by a perforated, technically designed handle that heats up less thanks to free air circulation.

Easy installation and preparation for automation

The MAGMA fireplace has been designed to facilitate the work of installers and provide complete design freedom:
■ Leveling feet (Ø 50 mm): adjustable pins with a tilting foot and rubber insert allow for perfect leveling of the device even on uneven surfaces, while the mounting flange allows for permanent attachment to the floor.
■ External air intake Ø 125 mm: allows for the intake of combustion air directly from outside the building.
■ Ready for automation (slots for sensors): the device has factory-prepared and secured with M8x1 screws locations for mounting a flue gas sensor (on both sides of the insert, optional) and a reed switch door opening sensor. This allows for seamless integration of the fireplace with advanced electronic controllers to automatically manage airflow without interfering with the structure of the fireplace.

Why choose a MAGMA fireplace?

■ Stovetop version: the perfect solution for custom fireplace installations.
■ Fireplace body: made of 4 mm thick steel.
■ TERMOTEC lining: available in light or dark versions, characterized by heat-accumulating properties - it releases energy into the environment. Soot particles are burned after reaching an operating temperature of 300°C. Thanks to this, even the light-colored TERMOTEC remains clean when it reaches its operating temperature.
■ Grateless combustion: the wood burns on the ash - less fuel loss, minimal fuel waste and maximization of energy use.
■ Full control over the combustion process: is controlled by a single, intuitive regulator that precisely manages all air channels and maintains their correct proportions, without the possibility of completely cutting off the supply.
■ Perforated handle: an ergonomic handle with a modern texture, ensuring comfortable opening and slower heating.
■ Heat-resistant glass: with temperature resistance up to 660°C.
■ Clean glass system: an air curtain that limits soot build-up.
/>■ Double glass door: guarantees better insulation and a higher temperature in the chamber, while double glazing effectively reduces the heating of the outer glass compared to single-glazed solutions.
■ Triple air supply system: primary air, secondary air and an air curtain to optimize the combustion process.
■ Deflector system: effectively extends the exhaust gas path, increases combustion efficiency and allows for better use of thermal energy.
■ Outside air intake: Ø125 mm connector allowing for the introduction of fresh air from outside the building.
■ Precise installation:Compact Ø50 mm leveling feet with a rubber insert facilitate stable positioning and attachment of the device even to uneven surfaces.
■ Factory slots for automation: Dedicated mounting points for the exhaust gas sensor (on both sides) and the door opening sensor (reed switch).
■ Ideal for heat recovery: airtight combustion chamber designed for modern, energy-efficient construction.
■ Meets the following standards: Ecodesign, BImSchV 2, Flamme Verte, Wallonair (BE), 5 Stelle Certificato ambiental (IT), DIN+ and 15a B-VG.
