Designations
Sku LEO/70/MANUAL/G20
Specification
Nominal power (kW) 7.3
Thermal Efficiency (%) 91.9
Certificates
- KRATKI PRO
- Designed for recuperation
Weight (kg) 90
Description
MAXIMUM USE OF ENERGY
Innovative, elegant gas insert with a horizontal and realistic vision of fire.
High quality, comfort and ease of use.
Undisturbed vision of fire thanks to the invisible frame of the façade and the minimum number of visible steel elements.
Specially designed burner provides a realistic vision of fire, like in a real wood-burning fireplace.
Additional flame height adjustment.
SAFETY AT THE HIGHEST LEVEL
The device has a CE certificate, which guarantees safety of use, protection of health and the environment.
Hermetically sealed combustion chamber, which gives the highest degree of safety; in case of any problems with the patency of the air-flue gas duct or gas supply, the fireplace is
COMFORTABLE USE
Cartridge with a closed combustion chamber and manual control, adapted to burn with natural gas. The installation does not require a traditional chimney - the coaxial cable system allows installation in rooms without a chimney, it is enough to lead the cable outside the building wall or roof.
Time control: the ability to program the daily temperature up to seven days in advance.
The device does not require an external power source (it has its own power supply system). The control panel is powered by 4 1.5V batteries. (optionally, you can purchase a second G 60-ZBE power module).
The set includes: - a gas insert adapted to burn natural gas - a manual control system - ceramic wood for lining the hearth.
The height of the flame in the fireplace depends on the quality of the gas.
Technical data
| Additional closing | No |
|---|---|
| Gas consumption with minimal heat load | 0,332 |
| Gas Consumption at Rated Heat Load | 0,692 |
| Thermal Efficiency (%) | 91.9 |
| Heating power range (kW) | 3,5 - 7,3 |
| Nominal power (kW) | 7.3 |
| Gas Type | G20/20MBAR |
| Control Type | Manual |
| Version | Front facing |
| Energy class | A |
|---|---|
| Heat output for space heating (kW) | 7.3 |
| EEI | 91.1 |
| Certificates | KRATKI PRO, Designed for recuperation |
|---|
| Fuel type | Natural gas (NG) |
|---|---|
| EAN | 5901350018859 |
| Weight (kg) | 90 |
|---|---|
| Width (cm) | 75.6 |
| Height (cm) | 81.6 |
| Depth (cm) | 37.5 |
